Refrigerant Line Arrangement for 2001 Mercedes-Benz S500
No.
Part # / Description / Price
15
Pressure Sensor
Mercedes-Benz
$159.00
Mercedes-Benz Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
40
O-Ring Mercedes-Benz
$3.20
Mercedes-Benz Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
45
Rear AC Line Guide Mercedes-Benz
$6.25
Mercedes-Benz Guide
Pipe line to condenser. Refrigerant line. At condenser. From condenser to liquid tank. Pressure line to condenser. Roof Mounted A/C. All Required. Center. Pipeline.
80
90
Mounting Clamp Mercedes-Benz
$9.50
Mercedes-Benz Clamp
Regeneration line to left front wheel arch. 10/15. Vent hose to activated charcoal filter. 10/15. Oil line to engine. 10/15.
140
O-Ring Mercedes-Benz
$4.00
Mercedes-Benz Pressure line to expansion valve. 7.5x2.1. Tubing at expansion valve. 7.5x2.1. Refrigerant line. 7.5x2.1.
190
Sealing Ring Mercedes-Benz
$3.70
Mercedes-Benz Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
220
270
Holder Mercedes-Benz
Mercedes-Benz Refrigerant line to crossmember. Clutch line to firewall. Fastening brake hose from hydraulics unit to brake unit. Hose at engine wiring harness bracket.
282
Sealing Ring Mercedes-Benz
Mercedes-Benz Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
345
Hexagon Head Bolt Mercedes-Benz
$2.20
Mercedes-Benz Climate line attachment. M6X30
Diameter: 6mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Actuator to bracket. Sensor mount to housing. Lateral support to bumper. Holder to transmission. Control unit to bracket. Pressure sensor attachment.
400
Ft Seat Air Bag Nut Mercedes-Benz
$2.80
Mercedes-Benz Nut
Air bags. 144 wheelbase. 170 wheelbase. Driver side. Passenger side. Reverse warning.
410
Feed-Through Grommet Mercedes-Benz
$7.25
Mercedes-Benz Mounting pipe line. Suction line to shock-absorber strut. Climate line attachment. Refrigerant line to wheelhouse. Piping mount. Refrigerant line to wheel well. Mounting, refrigerant line. Line to crossmember.
420
Snap Fastener Mercedes-Benz
Mercedes-Benz Mounting pipe line. Suction line to shock-absorber strut. Climate line attachment. Piping mount. At solenoid valve. Mounting solenoid valve.
440
Valve Element Mercedes-Benz
$19.50
Mercedes-Benz Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
443
Rear AC Line Guide Mercedes-Benz
$4.20
Mercedes-Benz Guide
Between line to compressor and line to expansion valve. Roof Mounted A/C. All Required. Front. Refrigerant line.
445
Sealing Ring Mercedes-Benz
$1.50
Mercedes-Benz Between line to compressor and line to expansion valve. 13x2.5. Separation point. 13x2.5.
460
Sealing Ring Mercedes-Benz
$3.60
Mercedes-Benz Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
500
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Sealing Ring
AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
540
