Closed Fuel-Evaporation-Control System for 2002 Mercedes-Benz C 320
No.
Part # / Description / Price
26
Sealing Ring
Mercedes-Benz
Mercedes-Benz Activated charcoal filter. Shutoff valve activated-carbon filter. At valve.
28
Electrical Wiring Harness Mercedes-Benz
MSRP $21.50
$21.50
Mercedes-Benz Shutoff valve adapter line. Activated charcoal filter shutoff valve.
30
Hose Mercedes-Benz
MSRP $32.50
$32.50
Mercedes-Benz 160 mm. 13.3x3 mm. From fuel filter to feed line. 13.3x3 mm. 300 mm. 13.3x3 mm. 110mm. 13.3x3 mm. Order by the meter. 13.3x3 mm. 250 mm. 13.3x3 mm. From activated charcoal filter to regeneration valve. 13.3x3 mm. 100 mm from fuel return line to fuel tark. 13.3x3 mm.
30
Hose Mercedes-Benz
MSRP $25.00
$25.00
Mercedes-Benz Activated charcoal filter for purge line. 15,3X3MM. Hose to valve 55mm. 15,3x3mm. Feed and return lines, breathing 55mm. 15,3x3mm. Return line to fuel filter 200mm. 15,3x3mm. Vent pipe fuel tank to t-fitting or vent valve 50mm. 15,3x3mm. Vent line 45 mm. 15,3x3mm. Purge line to check valve. 15,3x3mm. From activated charcoal filter to regeneration line. 15,3x3mm.
40
Spring Hose Clamp Mercedes-Benz
MSRP $6.50
$6.50
Mercedes-Benz Hose to activated charcoal filter. 27-30 mm. Mount, water drain at top. 27-30 mm. Hose attachment. 27-30 mm. Filler neck to charcoal filter. 27-30 mm. Return. 27-30 mm. Hose to engine. 27-30 mm. Hose to additional water pump. 27-30 mm. To coolant hose. 27-30 mm. From pump to heat exchanger. 27-30 mm. Low temperature pump. 27-30 mm.
60
Vent Tube Mercedes-Benz
Mercedes-Benz Purge Line
Activated charcoal filter to purge valve. From activated charcoal filter to regeneration valve.
70
Hose Mercedes-Benz
MSRP $7.75
$7.75
Mercedes-Benz Molded Hose
Fluid reservoir. Between tube and purge valve. From activated charcoal filter to regeneration valve. Regeneration line to distributor. Molded hose. Regeneration valve to intake pipe. At sender unit. Distributor to regeneration valve, right. Regeneration line to regeneration valve.
70
Hose Mercedes-Benz
Mercedes-Benz Fluid reservoir. Purge valve to connecting point. Activated charcoal filter to purge valve. Regeneration valve to throttle housing. To purge line. At intake manifold. Molded hose. From regeneration line to engine. Intake manifold to purge valve,left. From right regeneration valve to engine.
80
Purge Valve Mercedes-Benz
MSRP $87.00
$87.00
Mercedes-Benz Regeneration valve. Evaporative emission control system. In engine compartment. To engine.
80
80
Purge Valve Mercedes-Benz
Mercedes-Benz Regeneration valve. Evaporative emission control system. In engine compartment.
85
Holder Mercedes-Benz
MSRP $13.50
$13.50
Mercedes-Benz PURGE VALVE AT BRACKET
Inside diameter: 33,5mm
Outside diameter: 39,5mm
Material thickness: 3mm.
95
145
Clamp Mercedes-Benz
MSRP $3.60
$3.60
Mercedes-Benz Fuel filter to act. CARBON FILTER. 13-14/8.2 MMDiameter: 13mmInside diameter: 13,5mmOutside diameter: 15mmMaterial thickness: 0,6mmModel 1: Gelb. BETWEEN ACTIVATED CHARCOAL FILTER AND REGENERATION VALVE. 13-14/8.2 MMDiameter: 13mmInside diameter: 13,5mmOut ...
145
