Cable Harness Automobile Telephone for 2003 Mercedes-Benz C32 AMG

Mobile phone pre-installation. Ctel system preparation.

Portable ctel to dome or center con.

Ctel fixed inst. To dome.

Fixed ctel to "dome" nokia d-network.

Fixed ctel to "dome" nokia d-network.

Tele aid.

Mobile phone pre-installation.

Prep. For emergency call system.

Prep. For emergency system "e-call" (mobile ctel with voice control sys.).

D2b portable.

Communication.

Universal handy interface.

Operating unit.

"e-call" emergency call and sound system.

Communication / satellite radio and sound system.

Communication with sound system.

Fixed ctel system.

Ctel with emergency call system.

Comand with "emergency-call" system.

Telecommunications with comand.

Fixed ctel system.

On-board elec. Partition point microphone sound syst. Bus node connector (can) left (coding a) x30/5. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60. Central gateway control module. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60 ...

Connector: 4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Signal acquisition and actuation module with rear fuse and relay module. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Sam/srb control module rear black n10/2*4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1.

Control module sam/srb rear n10/2. 1-pin jpt. Front sam control module. 1-pin jpt. Fuse and relay box near driver's seat h2. 1-pin jpt. Fuse and relay box,front passenger side,single-pin. 1-pin jpt. Fuse and relay module, driver n10/1. 1-pin jpt. Co-driver's air bag. 1-pin jpt. Airbag, passenger side. 1-pin jpt.

Hitching mechanism plug-connection x52. 4-pin slk 2.8
model 1: slk
model 2: 2.8
slots: 4. Electrical center at trailer control unit x58/33. 4-pin slk 2.8
model 1: slk
model 2: 2.8
slots: 4. Door partition point front left, blue x35/41,. 4-pin slk 2.8
model 1: slk
model 2: 2.8
slots: 4.

Spt. Fuse/relay box. Fuse box interior light blue f34. Seat adjustment control unit f34/34.

Transceiver connector, blue x39/5. 10-pin mqs. Telephone-portable ctel separation point, blue x39/37*3. 10-pin mqs. Breakdown/information button conn. X39/48. 10-pin mqs. Blue center console connector x29/6. 10-pin mqs. Plug connection handy x39/39. 10-pin mqs. Mobile phone disconnecting point. 10-pin mqs. Connector, telephone, armrest, blue x39/47. 10-pin mqs.

To 168 545 09 40. Breakdown/information button conn.

Speed-sensitive power steering conn. Antenna module. 6-pin. Antenna amplifier to rear window to 001 545 51 40. 6-pin.

Plug distributor radio mute x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio "mute" plug connection x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. ...

Left front door connector, green x35/1. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Emergency speaker connector right front x18/36. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pin slk2 ...

Microphone array control module (n41/5). 20-pin.

Electronic ignition lock (ezs) control unit n73*2. 2-pin mcp2.8. Signal acquisition and actuation module with rear fuse and relay module. 2-pin mcp2.8. Front sam/srb control module, neutral n10/1,. 2-pin mcp2.8. Sam/srb control module rear neutral n10/2, code b. 2-pin mcp2.8. Fuse and relay module, driver n10/1 / 11. 2-pin mcp2.8.

CONNECTOR: A26/17*1C. 12-PIN MQS
Model 1: MQS
Slots: 12
Release tool: W220 589 01 99 60. Audio/comand control panel a40/3*c. 12-pin mqs
model 1: mqs
slots: 12
release tool: w220 589 01 99 60.

Fuse and relay module, rear n10/2 5. Srb. 2-pin mcp2.8.

Plug Housing

To a 000 545 95 03. To a 001 545 51 40. T0 a 001 545 52 40. To a 001 545 520 40. To a 001 545 28 81. To 001 545 52 40.

Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.

Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.

BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...

Crimp Tml. Pin Contact

X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...

Silver-plated. 0.22-0.35 MM2 SLK2.8Leitungsquerschnitt Min/Max: 0,22-0,35mm2Oberflächenschutz PINs: AgELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. Single-wire seal. 0.22-0.35 MM2 SLK2.8Leitungsquerschnitt Min ...

Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...

Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.

E-call speaker. Loadspeaker for emergency call.

WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.

Connector distributor wake-up/ diagnostics 10-pin x30/14. 10-pin slk2.8. Distributor, terminal 58d x30/13. 10-pin slk2.8. Connector distributor wake-up/ diagnostics 10-pin x 30/14. 10-pin slk2.8. Potential distributor kl.31 z204/5. 10-pin slk2.8. Plug distributor wake-up signal 10 pin x30/8,. 10-pin slk2.8. Below left rear seat z204/6. 10-pin slk2.8. Distributor, terminal 15 x30/9,code a. 10-pin slk2.8.
