Soft Top Mechanics for 2003 Mercedes-Benz CLK500

130

Hexalobular Screw

MSRP $2.70

$2.70

000000-001476

Mercedes-Benz

Pneumatic spring to flap.

150

Soft Top Lock

209-770-02-26

Mercedes-Benz

Closure

To soft top front.

View Details

155

Stop Buffer

209-774-04-41

Mercedes-Benz

To soft top front.

View Details

160

Screw

MSRP $6.00

$6.00

000-984-35-29

Mercedes-Benz

190

Blind Rivet

MSRP $1.40

$1.40

004-990-35-97

Mercedes-Benz

FRAME TO POCKET 13X9.5Diameter: 3,2mmOutside diameter: 9,5mm. AT BOW 13X9.5Diameter: 3,2mmOutside diameter: 9,5mm. LEFTDiameter: 3,2mmOutside diameter: 9,5mm. PICK-UP STRIP 13X9.5Diameter: 3,2mmOutside diameter: 9,5mm. RETAINING BRACKET 13X9.5Diameter: 3,2 ...

200

Bracket

209-774-02-33

Mercedes-Benz

Left. Right front bow.

View Details

200

Bracket

209-774-01-33

Mercedes-Benz

Right. Left front bow.

View Details

220

Bracket

209-774-04-33

Mercedes-Benz

Right rear bow.

View Details

240

Cap

209-773-01-23

Mercedes-Benz

Left rear roof rail.

View Details

240

Cap

209-773-02-23

Mercedes-Benz

Right rear roof rail.

View Details

250

Seal

MSRP $137.00

$137.00

209-770-02-98

Mercedes-Benz

Front right.

250

Seal

MSRP $147.00

$147.00

209-770-01-98

Mercedes-Benz

Front left.

260

2077700698 - Soft Top: Seal for Mercedes-Benz Image image

Seal, Soft Top

MSRP $212.00

$212.00

207-770-06-98

Mercedes-Benz

Seal

Central right.

260

2077700598 - Soft Top: Seal for Mercedes-Benz Image image

Seal, Soft Top

MSRP $180.00

$180.00

207-770-05-98

Mercedes-Benz

Seal

Central left.

270

Seal, Soft Top

MSRP $234.00

$234.00

207-770-13-00

Mercedes-Benz

Rear.

270

Seal

MSRP $374.00

$374.00

209-770-00-98

Mercedes-Benz

Rear.

280

Seal

209-778-05-96

Mercedes-Benz

Moss type rubber.

View Details

290

Hexalobular Screw

MSRP $2.70

$2.70

000000-001883

Mercedes-Benz

Cables to cable connector.

290

Hexalobular Screw

MSRP $6.00

$6.00

000000-001517

Mercedes-Benz

300

Rail

MSRP $132.00

$132.00

209-774-00-47

Mercedes-Benz

Retaining bracket.

310

Clip

MSRP $3.10

$3.10

912007-010001

Mercedes-Benz

LOCK FOR BOLT TO CYLINDER ON VARIO ROOF AT LEFT AND RIGHT REAR
Diameter: 10mm
Thread code letter: DBL8451.12
Inside diameter: 2,5mm
Outside diameter: 3,5mm. LEVER TO FOLDING TOP SUPPORT
Diameter: 10mm
Thread code letter: DBL8451.12
Inside diameter: 2,5mm
Outside diameter: 3,5mm.

320

Mechanical Securing

MSRP $3.60

$3.60

912002-008003

Mercedes-Benz

330

Intermediate Layer

209-778-08-97

Mercedes-Benz

Rear bow.

View Details

340

Washer

MSRP $0.90

$0.90

000125-006449

Mercedes-Benz

Cable to terminal b+. Positive cable to battery.

355

End Stop

209-774-02-41

Mercedes-Benz

Roof front rail.

View Details

360

30403200800665 - Soft Top: Hexagon Nut for Mercedes-Benz Image image

Wiper Arm Nut

MSRP $3.40

$3.40

304032-008006-65

Mercedes-Benz

Hexagon Nut

Master cylinder to brake booster. Rear bumper to rear body panel cross member. Electric cable to alternator. Pedal assembly to fire wall. Front bumper to cross member. Armrest to backrest. Bracket to bumper. Left stiffening to right stiffening. On front door,bottom.

370

End Stop

209-774-03-41

Mercedes-Benz

Roof rear rail.

View Details

375

Countersunk Screw

MSRP $7.50

$7.50

140-984-42-29

Mercedes-Benz

Evo tensioner to crash locking mechanism, rh. M8x16. Left seat. Eccentric at rear closure. Screw to housing. Folding top to frame. Lock covering. Plate, cable covering, on plate, front. Mount, left cover.

380

Hexalobular Screw

MSRP $0.90

$0.90

000000-003251

Mercedes-Benz

Fastening amplifier. M5X12
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Mounting, handle. Light switch module on dashboard. Glove compartment bracket.

400

Rivet

MSRP $1.70

$1.70

004-990-36-97

Mercedes-Benz

BAND AT FRAME BRACKET 19.5X9.5
Diameter: 3,2mm
Outside diameter: 9,5mm.

410

Retaining Rail

209-770-07-05

Mercedes-Benz

Left rear roof rail.

View Details

410

Soft Top Frame

209-770-08-05

Mercedes-Benz

Right rear roof rail.

View Details

440

Screw

MSRP $2.90

$2.90

002-990-99-12

Mercedes-Benz

Transmission to jacket tube. M5x10. Slider at jacket tube. Frame. Fore-and-aft adjustment. Transmission, longitudinal adjustment on jacket tube.

470

Clamp

MSRP $2.20

$2.20

208-779-00-70

Mercedes-Benz

Lining. At retaining rail.

500

Plate

209-770-02-23

Mercedes-Benz

Right.

View Details

500

Plate

209-770-01-23

Mercedes-Benz

Left.

View Details

520

Rail

MSRP $58.00

$58.00

209-770-06-34

Mercedes-Benz

Rear window on the right.

520

Rail

209-770-05-34

Mercedes-Benz

Rear window on the left.

View Details

530

Sliding Shoe

MSRP $8.00

$8.00

209-782-00-57

Mercedes-Benz

Guide rail.

535

Collar Pin

MSRP $13.00

$13.00

209-991-15-05

Mercedes-Benz

Slide.

540

Clip

MSRP $3.80

$3.80

912007-005000

Mercedes-Benz

LEFT AND RIGHT
Diameter: 5mm
Thread code letter: DBL8451.12. SLIDE
Diameter: 5mm
Thread code letter: DBL8451.12. Inside door handle central locking, driver side
diameter: 5mm
thread code letter: dbl8451.12. Brake pedal sensitive parking shift lock
diameter: 5mm
thread code letter: dbl8451.12.

550

Holder

209-640-02-51

Mercedes-Benz

Right.

View Details

550

Holder

209-640-01-51

Mercedes-Benz

Left.

View Details

560

Blind Rivet

MSRP $1.40

$1.40

000-991-12-32

Mercedes-Benz

Bracket.

570

Snap Fastener

MSRP $1.60

$1.60

001-988-19-81

Mercedes-Benz

Bottom.

580

Snap Fastener

MSRP $2.80

$2.80

001-988-18-81

Mercedes-Benz

Top.
