Foot Operated Parking Brake for 2004 Mercedes-Benz C32 AMG
No.
Part # / Description / Price
50
Cover
Mercedes-Benz
$11.50
Mercedes-Benz Pedal to 163 420 02 84/03 84. On foot-operated parking brake. Pedal to 208 420 00 84.
110
Hexagon Head Bolt Mercedes-Benz
$6.00
Mercedes-Benz Screw
M8X22
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Foot-operated parking brake to front panel pillar. Fastening, foot-operated parking brake. Distributor to bracket. Foot operated parking brake to fire wall m 8x22. Foot operated parking brake to fire wall m8 x 22.
135
End Stop Mercedes-Benz
Mercedes-Benz Release for foot operated parking brake. To guide. Armrest. Release handle. Unlocking foot operated parking brake. Left and right.
Not For Sale
180
Hose Mercedes-Benz
Mercedes-Benz Front brake cable to parking brake. Brake cable to brake lever. For ground cable, fuel pump order by the meter. 12 mm. Front brake cable 15mm. On wire spiral, choke cable order by the meter.
190
Cable Bracket Mercedes-Benz
$3.40
Mercedes-Benz Brake control cable to tunnel. Brake cable to frame. Front brake cable to fire wall. Brake cable guide. Front brake cable to tunnel. Brake cable 11 mm.
200
Fastening Clamp Mercedes-Benz
Mercedes-Benz Front brake cable to fire wall. Brake control cable to tunnel. Front cable to firewall. On fire wall. At refrigerant line,for rear space heating. Cable harness to wiper motor plug. Front brake cable to tunnel. Hose to body.
220
Nut Mercedes-Benz
Mercedes-Benz Spring strut to body. M8
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
280
300
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Brake cable to wheel carrier. M8X16
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Brake cable to rear axle. End stop to frame. Front subframe carrier. Brake cable to bracket. Parking brake to tunnel m8x16. Engine mounting to engine support.
320
Cable Bracket Mercedes-Benz
$4.50
Mercedes-Benz Under mounting bolt of brake cable. Rear axle wiring on wheel carrier,left. To wheel carrier.
330
Cable Bracket Mercedes-Benz
Mercedes-Benz On cover panel right of rear axle for rear axle f/brake lini.wear disp.lini. Rear cover plate.
340
Snap Fastener Mercedes-Benz
$3.50
Mercedes-Benz Adjuster. Attachment cover left. Fastening, left trim. Left trim mount. Mounting, cover.
