Control Modules, Fuse and Relay Box in En-Gine Compartment, Front Left for 2006 Mercedes-Benz SLK280
No.
Part # / Description / Price
10
Elec Center, Base Module 1
Mercedes-Benz
Mercedes-Benz Elec. Center, Base Module
Signal acquisition + actuation module with front fuse and relay module sam. Sam/srb.
200
Relay Mercedes-Benz
Mercedes-Benz Rear, pos. C,f. Front. HEATED REAR WINDOW PANE RELAYModel 2: Schliesser / closing contactVolt: 12VAmps: 50A. PLUG POSITION: NModel 2: Schliesser / closing contactVolt: 12VAmps: 50A. RELAY SLOT 0, SECONDARY AIR PUMPModel 2: Schliesser / closing contactVolt: ...
200
Relay Mercedes-Benz
MSRP $27.00
$27.00
Mercedes-Benz Slot K
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT J
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. PLUG POSITION C
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT D
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. Slot P
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A.
210
Fuse Mercedes-Benz
MSRP $5.25
$5.25
Mercedes-Benz Fuse Link
Charge level recognition f96. Rear fuse box. Blade fuse ATO. Front, 7.5 amp. Trunk, 7.5 amp. Interior, 7.5 amp. Slot 16 lumbar support adjustment. Slot 3, portable ctel uhi.
900
Coupling, Mechanical Mercedes-Benz
MSRP $19.00
$19.00
Mercedes-Benz Prefuse box, battery compartment f33*mf2. 6-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 6. Front passenger footwell fuse and relay box f1/6. 6-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 6. Fuse box. plug: F1/6*MF2. 6-PIN MCP2.8Model 1: MCPModel 2: 2.8Slots: 6. ...
900
Plug Mercedes-Benz
MSRP $8.00
$8.00
Mercedes-Benz On-board elec. Partition point microphone sound syst. Bus node connector (can) left (coding a) x30/5. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60. Central gateway control module. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60 ...
900
Socket-Outlet Mercedes-Benz
MSRP $13.00
$13.00
Mercedes-Benz Airscarf control unit n25/7. 10-pin mqs. Fuse and relay box,driver n10/1/10. 10-pin mqs. Heated seats and seat ventilation n25/7. 10-pin mqs. Door control unit at driver door, left and right n69/1. N69/2. 10-pin mqs.
900
Plug Mercedes-Benz
MSRP $8.25
$8.25
Mercedes-Benz Prefuse box, battery compartment f33*mf3. 6-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 6. Fuse and relay box, a-pillar f1/6. 6-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 6. Fuse box. plug: F1/6*MF1. 6-PIN MCP2.8
Model 1: MCP
Model 2: 2.8
Slots: 6. Control module sam/srb front, violet n10/1. 6-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 6. Fuse and relay module, driver n10/1,code d. 6-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 6.
900
Plug Mercedes-Benz
Mercedes-Benz Electronic ignition lock (ezs) control unit n73*2. 2-pin mcp2.8. Signal acquisition and actuation module with rear fuse and relay module. 2-pin mcp2.8. Front sam/srb control module, neutral n10/1,. 2-pin mcp2.8. Sam/srb control module rear neutral n10/2, code b. 2-pin mcp2.8. Fuse and relay module, driver n10/1 / 11. 2-pin mcp2.8.
900
Plug Mercedes-Benz
MSRP $4.10
$4.10
Mercedes-Benz Left rear door control module n69/8. 4-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 4release tool: w000 589 13 99 30. Taillamp left E3/1. 4-PIN MCP2.8Model 1: MCPModel 2: 2.8Slots: 4Release tool: W000 589 13 99 30. Control module keyless go black n69/9. 4-pin ...
900
Plug Mercedes-Benz
MSRP $8.50
$8.50
Mercedes-Benz Electrical center, left front, black, 10-pin n10/1. Mr5. 10-pin slk 2.8. Control module sam/srb rear n 10/2. 10-pin slk 2.8. Front SAM/SRB control unit. 10-PIN SLK 2.8. Seat adjustment switch s22. S23. 10-pin slk 2.8. Control module sam/srb front, black n10/1,. 10-pin slk 2.8. Electr.seat adjust.switch s91. 10-pin slk 2.8. Seat adjustment switch. 10-pin slk 2.8. Fuse and relay module, driver n10/1 ,code a. 10-pin slk 2.8.
900
Plug Mercedes-Benz
Mercedes-Benz Spt. Fuse/relay box. Fuse box interior light blue f34. Seat adjustment control unit f34/34.
900
Fuse Box Mercedes-Benz
MSRP $7.25
$7.25
Mercedes-Benz Cod. B SPT
Slots: 1. Rear sam/srs-fp control module slot 20 n10/2. Fuse box interior plug position 30 f34. Fuse box, interior, orange f34. Control unit, heated seats and head area ventilation f34/23. Fuse and relay module, rear n10/2. Fuse box interior violet.
900
Plug Mercedes-Benz
MSRP $5.25
$5.25
Mercedes-Benz 3rd stop lamp e21. 2-pin mqsmodel 1: mqsslots: 2. Signal acquisition + actuation module with front fuse and relay module n10/1. 2-pin mqsmodel 1: mqsslots: 2. Heated washer nozzle r2/8. 2-pin mqsmodel 1: mqsslots: 2. Control module sam/srb front, green n10 ...
900
Plug Mercedes-Benz
MSRP $13.00
$13.00
Mercedes-Benz CONNECTOR 9. 8-PIN SLK2.8Model 1: SLKModel 2: 2.8Slots: 8Release tool: W220 589 01 99 62. Seat adjustment control unit n31,n32. 8-pin slk2.8model 1: slkmodel 2: 2.8slots: 8release tool: w220 589 01 99 62. Sam control unit with fuse and relay module, passen ...
900
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz "sam" control unit rear. 4-pin mcp 2.8. Control module sam/srb front, blue n10/1,. 4-pin mcp 2.8. Sam/srb control module, rear blue n10/2, code c. 4-pin mcp 2.8. Central locking system n10/2 13. 4-pin mcp 2.8. Fuse and relay module, driver n10/1/12. 4-pin mcp 2.8.
900
Plug Mercedes-Benz
MSRP $6.00
$6.00
Mercedes-Benz Front sam/srb control module, neutral i2. Roof lamp, rear E15/3. 4-PIN MCP2.8. Front sam/srb control module, neutral n10/1,. 4-pin mcp2.8. Rear dome lamp. 4-pin mcp2.8. Fuse and relay module, driver n10/1, code b. 4-pin mcp2.8.
901
Contact Socket Mercedes-Benz
MSRP $6.00
$6.00
Mercedes-Benz STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
901
Contact Spring Mercedes-Benz
MSRP $3.90
$3.90
Mercedes-Benz Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
901
Electric Line Mercedes-Benz
Mercedes-Benz With single-wire seal. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgModel 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62. SOUND AMPLIFIER N40/3,N93/1. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PIN ...
901
Electric Line Mercedes-Benz
MSRP $11.50
$11.50
Mercedes-Benz WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
901
Contact Socket Mercedes-Benz
MSRP $4.10
$4.10
Mercedes-Benz Fuse and relay module, front passenger k40/4. I1. 6.0-10.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. With single-wire seal. 6.0-10.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
901
Electrical Wiring Harness Mercedes-Benz
MSRP $12.00
$12.00
Mercedes-Benz Silver-plated. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgModel 1: LSKModel 2: 8Release tool: W220 589 01 99 56. Central electrics in eng. COMPARTMENT LEFT FRONT N10/1. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Obe ...
901
Contact Socket Mercedes-Benz
MSRP $7.00
$7.00
Mercedes-Benz BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
901
Contact Spring Mercedes-Benz
MSRP $3.50
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
902
Plug Mercedes-Benz
MSRP $8.50
$8.50
Mercedes-Benz Connector cockpit/frame floor system x18*2. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Separation point trunk lid 6-pin x8/4. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Connector for engin ...
902
Coupling, Mechanical Mercedes-Benz
MSRP $10.50
$10.50
Mercedes-Benz Door control module left, black n69/1. 7-pin mqs/mcp2.8. Front left door control. 7-pin mqs/mcp2.8. Control module sam/srb front, black n10/1. 7-pin mqs/mcp2.8. Fuse and relay module, driver n10/1 / 15. 7-pin mqs/mcp2.8. Door control unit at driver door, left and right n69/1 n69/2. 7-pin mqs/mcp2.8.
903
Coupling, Mechanical Mercedes-Benz
MSRP $9.50
$9.50
Mercedes-Benz Connector: 2g. 2-pin lsk8. Sam/srb control module rear black n10/1. 2-pin lsk8. Front prefuse box F32. 2-PIN LSK8. Control module sam/srb front, black n10/1,. 2-pin lsk8. Fuse and relay module, driver n10/1 /8. 2-pin lsk8.
903
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz "sam" control unit rear n10/2. 2-pin mcp2.8. Sam/srb control module, rear blue n10/2,2-pin,code c. 2-pin mcp2.8. Fuse and relay module, driver n10/1 /21. 2-pin mcp2.8.
903
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Control module sam/srb rear n10/2. 1-pin jpt. Front sam control module. 1-pin jpt. Fuse and relay box near driver's seat h2. 1-pin jpt. Fuse and relay box,front passenger side,single-pin. 1-pin jpt. Fuse and relay module, driver n10/1. 1-pin jpt. Co-driver's air bag. 1-pin jpt. Airbag, passenger side. 1-pin jpt.
903
Receptacle Mercedes-Benz
MSRP $4.50
$4.50
Mercedes-Benz Coupling, Mechanical
Sam control unit. 3-pin. Fuse and relay module, driver n10/1 /1. 3-pin. Fuse and relay module, rear n10/2 3. Srb. 3-pin.
905
Plug Mercedes-Benz
MSRP $8.75
$8.75
Mercedes-Benz Driver partially electric seat adjustment switch s22/1*1. 12-pin slk2.8model 1: slkmodel 2: 2.8slots: 12release tool: w220 589 01 99 62. M1. 12-PIN SLK2.8Model 1: SLKModel 2: 2.8Slots: 12Release tool: W220 589 01 99 62. Switch for seat adjustment,left s22. ...
905
Coupling, Mechanical Mercedes-Benz
MSRP $7.50
$7.50
Mercedes-Benz Electrical center, left front, transparent, 10-pin n10/1. Mr6. 10-pin slk2.8. Front SAM/SRB control unit. 10-PIN SLK2.8. Front sam/srb control module, neutral n10/1,. 10-pin slk2.8. Fuse and relay module, driver n10/1 /3. 10-pin slk2.8.
905
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Signal acquisition + actuation module with front fuse and relay module n10/1. 3-pin mcp2.8. Control module sam/srb front, blue n10/1,. 3-pin mcp2.8. Fuse and relay module, driver n10/1 /24. 3-pin mcp2.8.
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
