Refrigerant Line Routing for 2010 Mercedes-Benz C300
No.
Part # / Description / Price
20
A/C Line O-Ring
Mercedes-Benz
MSRP $5.75
$5.75
Mercedes-Benz Sealing Ring
AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
30
O-Ring Mercedes-Benz
MSRP $3.20
$3.20
Mercedes-Benz Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
35
Rear AC Line Guide Mercedes-Benz
MSRP $6.50
$6.50
Mercedes-Benz Guide
Pipe line to condenser. Refrigerant line. At condenser. From condenser to liquid tank. Pressure line to condenser. Roof Mounted A/C. All Required. Center. Pipeline.
90
Pressure Sensor Mercedes-Benz
MSRP $162.00
$162.00
Mercedes-Benz Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
120
120
140
O-Ring Mercedes-Benz
MSRP $4.20
$4.20
Mercedes-Benz Pressure line to expansion valve. 7.5x2.1. Tubing at expansion valve. 7.5x2.1. Refrigerant line. 7.5x2.1.
150
Valve Element Mercedes-Benz
MSRP $20.00
$20.00
Mercedes-Benz Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
250
Refrigerant Line Mercedes-Benz
MSRP $234.00
$234.00
Mercedes-Benz From expansion valve to separation point. From expansion valve to connecting point.
250
260
Sealing Ring Mercedes-Benz
Mercedes-Benz Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
310
Feed-Through Grommet Mercedes-Benz
MSRP $7.50
$7.50
Mercedes-Benz Mounting pipe line. Suction line to shock-absorber strut. Climate line attachment. Refrigerant line to wheelhouse. Piping mount. Refrigerant line to wheel well. Mounting, refrigerant line. Line to crossmember.
320
Snap Fastener Mercedes-Benz
MSRP $6.00
$6.00
Mercedes-Benz Mounting pipe line. Suction line to shock-absorber strut. Climate line attachment. Piping mount. At solenoid valve. Mounting solenoid valve.
360
Sealing Ring Mercedes-Benz
MSRP $3.60
$3.60
Mercedes-Benz Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
400
Feed-Through Grommet Mercedes-Benz
Mercedes-Benz Pipe through partition wall, upper section. Piping through partition, upper part.
410
Feed-Through Grommet Mercedes-Benz
Mercedes-Benz Pipe through partition wall, lower section. Piping through partition, lower part.
450
Spacer Mercedes-Benz
MSRP $7.25
$7.25
Mercedes-Benz Bowden cable to heating feed hose. Compressor-to-condenser refrigerant line to side member. Oil pressure gauge line to speedometer drive shaft. Sensor cable 8 mm.
460
Hose Bracket Mercedes-Benz
MSRP $8.00
$8.00
Mercedes-Benz ACTUATOR FASTENING. 18/20 MMInside diameter: 18mmOutside diameter: 20mm. MOUNTING PIPE LINE. 18/20 MMInside diameter: 18mmOutside diameter: 20mm. CABLE TO AC HOUSING. 18/20 MMInside diameter: 18mmOutside diameter: 20mm. SPACER. 18/20 MMInside diameter: 18m ...
500
Retaining Clamp W Shackle Mercedes-Benz
Mercedes-Benz Mounting pipe line. Pipe line to partition panel. Piping mount.
540
540
Cap Screw Mercedes-Benz
MSRP $6.00
$6.00
Mercedes-Benz M8X30-10.9
Diameter: 8mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Steering coupling to steering shaft. Line to compressor. Stop buffer to frame. Plug connection, separation point.
900
Contact Socket Housing Mercedes-Benz
MSRP $6.00
$6.00
Mercedes-Benz Coolant pressure/temperature sensor b12. 3-pin mqsmodel 1: mqsslots: 3. Alarm unit h3/1. 3-pin mqsmodel 1: mqsslots: 3. Damping module at rear y53, y54. 3-pin mqsmodel 1: mqsslots: 3. Front damping module y51, y52. 3-pin mqsmodel 1: mqsslots: 3. Front door ...
