Soft Top Mechanics for 2014 Mercedes-Benz E 550
No.
Part # / Description / Price
110
Screw
Mercedes-Benz
MSRP $1.50
$1.50
Mercedes-Benz Roof mechanism mountDiameter: 4mmStrength / hardness class: 8.8Thread code letter: MThread pitch: 0,8mm. WIRING HARNESS TO REAR WINDOW FRAMEDiameter: 4mmStrength / hardness class: 8.8Thread code letter: MThread pitch: 0,8mm. MOUNTING HEATER UNIT TO BRACKET ...
140
Blind Rivet Mercedes-Benz
MSRP $1.40
$1.40
Mercedes-Benz FRAME TO POCKET 13X9.5Diameter: 3,2mmOutside diameter: 9,5mm. AT BOW 13X9.5Diameter: 3,2mmOutside diameter: 9,5mm. LEFTDiameter: 3,2mmOutside diameter: 9,5mm. PICK-UP STRIP 13X9.5Diameter: 3,2mmOutside diameter: 9,5mm. RETAINING BRACKET 13X9.5Diameter: 3,2 ...
210
Blind Rivet Mercedes-Benz
MSRP $1.70
$1.70
Mercedes-Benz Retaining bracket to bracket 19.5x14. Plate to integral carrier.
310
Clip Mercedes-Benz
MSRP $3.10
$3.10
Mercedes-Benz LOCK FOR BOLT TO CYLINDER ON VARIO ROOF AT LEFT AND RIGHT REAR
Diameter: 10mm
Thread code letter: DBL8451.12
Inside diameter: 2,5mm
Outside diameter: 3,5mm. LEVER TO FOLDING TOP SUPPORT
Diameter: 10mm
Thread code letter: DBL8451.12
Inside diameter: 2,5mm
Outside diameter: 3,5mm.
360
Wiper Arm Nut Mercedes-Benz
MSRP $3.40
$3.40
Mercedes-Benz Hexagon Nut
Master cylinder to brake booster. Rear bumper to rear body panel cross member. Electric cable to alternator. Pedal assembly to fire wall. Front bumper to cross member. Armrest to backrest. Bracket to bumper. Left stiffening to right stiffening. On front door,bottom.
390
Screw Mercedes-Benz
MSRP $6.50
$6.50
Mercedes-Benz Bracing wire to fabric retaining rail. Hardtop,front. Eccentric fastening. Fastening of slider.
390
Countersunk Screw Mercedes-Benz
MSRP $7.50
$7.50
Mercedes-Benz Evo tensioner to crash locking mechanism, rh. M8x16. Left seat. Eccentric at rear closure. Screw to housing. Folding top to frame. Lock covering. Plate, cable covering, on plate, front. Mount, left cover.
400
Rivet Mercedes-Benz
MSRP $1.70
$1.70
Mercedes-Benz BAND AT FRAME BRACKET 19.5X9.5
Diameter: 3,2mm
Outside diameter: 9,5mm.
450
Cap Screw Mercedes-Benz
MSRP $3.40
$3.40
Mercedes-Benz BRAKE LINE TO STEERING KNUCKLE
Diameter: 6mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. SOFT TOP FRAME AT CENTER AT FRAME
Diameter: 6mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
480
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz CROSS MEMBER TO TUNNEL
Diameter: 8mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. SOFT TOP, REAR
Diameter: 8mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm.
