Rear Axle Carrier for 2015 Mercedes-Benz C400
No.
Part # / Description / Price
20
Axle Sub-Frame Suspension
Mercedes-Benz
$48.50
Mercedes-Benz Axle Subframe Suspension
Rear subframe to frame floor unit, front. 85mm. Left and right front. 85MM. Rear axle carrier to front frame floor assembly .. 85MM.
30
Axle Sub-Frame Suspension Mercedes-Benz
$55.00
Mercedes-Benz Axle Subframe Suspension
Left and right rear. Rear axle carrier to rear frame floor assembly.
40
Rubber Bushing Mercedes-Benz
$29.50
Mercedes-Benz Spring link to rear axle bracket left. Spring link to left rear axle carrier. Spring control arm to rear subframe.
50
Rear Axle Diff Mount Mercedes-Benz
$37.00
Mercedes-Benz Rear Axle Diff. Mount
Axle housing to rear axle carrier, rear.
130
Screw W Washer Assembly Mercedes-Benz
$18.50
Mercedes-Benz Rear axle carrier to front frame floor assembly. Rear subframe to frame floor unit, front. Screwith bolt, decoupling element, front, rear axle carrier.
200
Adapter, Ra Diff Bearing Mercedes-Benz
Mercedes-Benz Adapter, Ra Diff. Bearing
Rear axle differential to front cross brace.
200
Adapter, Ra Diff Bearing Mercedes-Benz
Mercedes-Benz Adapter, Ra Diff. Bearing
Rear axle differential to front cross brace.
210
Hexalobular Head Screw Mercedes-Benz
$5.00
Mercedes-Benz Bearing to rear axle. M14x1,5x92. Differential to cross stabilizer front.
220
Window Mercedes-Benz
Mercedes-Benz BEARING TO REAR AXLE
Diameter: 15mm
Inside diameter: 15mm
Outside diameter: 50mm
Material thickness: 2mm. INTEGRAL CARRIER TO LONGITUDINAL MEMBER, FRONT
Diameter: 15mm
Inside diameter: 15mm
Outside diameter: 50mm
Material thickness: 2mm. DIFFERENTIAL TO CROSS STABILIZER FRONT
Diameter: 15mm
Inside diameter: 15mm
Outside diameter: 50mm
Material thickness: 2mm.
230
Nut, Special Form Mercedes-Benz
$6.00
Mercedes-Benz Bearing to rear axle. M14x1,5. Spring link to left wheel carrier. Spring control arm to wheel bearing left.
240
Hexalobular Head Screw Mercedes-Benz
$8.75
Mercedes-Benz Rear axle differential to front cross brace. M10x93. Adapter to rear axle centerpiece.
240
Hexalobular Screw Mercedes-Benz
$2.90
Mercedes-Benz Differential to cross stabilizer front. M10X42
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Rear axle differential to front cross brace. Adapter to rear axle centerpiece.
240
Hexalobular Screw Mercedes-Benz
$18.50
Mercedes-Benz Rear axle differential to front cross brace. M10X45
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Differential to cross stabilizer front.
250
Spacer Disk Mercedes-Benz
$5.50
Mercedes-Benz Adapter to rear axle centerpiece. 2mm. Differential to cross stabilizer front 2mm. 2mm. Rear axle differential to front cross brace 2mm. 2mm. As required 2.0 mm. 2mm. As required, no. Of notches:. 2mm. As required 2.00 mm. 2mm.
250
Spacer Disk Mercedes-Benz
$4.70
Mercedes-Benz Adapter to rear axle centerpiece. 1 mm. Differential to cross stabilizer front 1 mm. 1 mm. Rear axle differential to front cross brace 1 MM. 1 MM. As required 1.0 mm. 1 mm. As required, no. Of notches:. 1 mm. As required 1.00 mm. 1 mm.
250
Spacer Disk Mercedes-Benz
$5.75
Mercedes-Benz Adapter to rear axle centerpiece. 4 mm. Differential to cross stabilizer front 4 mm. 4 mm. Rear axle differential to front cross brace 4 MM. 4 MM. As required 4.0 mm. 4 mm. As required, no. Of notches:. 4 mm. As required 4.00 mm. 4 mm.
250
Spacer Disk Mercedes-Benz
$6.00
Mercedes-Benz Adapter to rear axle centerpiece. 3 mm. Differential to cross stabilizer front 3 mm. 3 mm. Rear axle differential to front cross brace 3 MM. 3 MM. As required 3.0 mm. 3 mm. As required, no. Of notches:. 3 mm. As required 3.00 mm. 3 mm.
290
Hexalobular Head Screw Mercedes-Benz
$2.60
Mercedes-Benz Rear axle differential to left rear crossmember. M14x1,5x70. Rear axle differential to rear cross brace. Rear axle differential to left rear cross bridge. Extension to cross-bar at left rear. Left and right adapter to bearing bracket. Bearing bracket to left and right rear axle differential bearing. Rear axle differential to right rear crossmember.
300
Front Support Washer Mercedes-Benz
$3.00
Mercedes-Benz Window
Crossmember mountDiameter: 14mmInside diameter: 14mmOutside diameter: 30mmMaterial thickness: 2,5mm. Support to left and right bodyDiameter: 14mmInside diameter: 14mmOutside diameter: 30mmMaterial thickness: 2,5mm. Bearing bracket to left and right rear ax ...
