Brake Booster for 2016 Mercedes-Benz E350
No.
Part # / Description / Price
30
Gasket
Mercedes-Benz
$5.25
Mercedes-Benz Brake booster assembly to fire wall. Brake servo. Between brake unit and firewall.
40
Nut Mercedes-Benz
Mercedes-Benz Spring strut to body. M8
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
50
Pin Mercedes-Benz
$7.00
Mercedes-Benz Pedal assembly to firewall. Brake booster assembly to pedal. Brake unit to pedal.
120
Sealing Ring Mercedes-Benz
$12.00
Mercedes-Benz MASTER CYLINDER TO BRAKE BOOSTER. 44 X 2.6
Diameter: 49,6mm
Inside diameter: 44,4mm
Outside diameter: 49,6mm
Material thickness: 3,1mm.
160
Reservoir Cap Mercedes-Benz
$15.00
Mercedes-Benz Cap
Expansion tank. Brake fluid reservoir. Sedan,. Container. To expansion reservoir.
170
Brake Master Cylinder Reservoir Strainer Mercedes-Benz
Mercedes-Benz Sieve
Coupe, convertible,. Expansion reservoir. Container. In compensation reservoir. Brake fluid reservoir. Teves. Expansion tank.
180
Mounting Plate Mercedes-Benz
$19.50
Mercedes-Benz Expansion reservoir to master cylinder. At frame. Brake booster.
210
Protective Cap Mercedes-Benz
$2.50
Mercedes-Benz At intake manifold. On check valve. Electric change-over valve to left side member below rear seat,left. On 3-way distributor. Auxiliary heating. Change-over valve 1/c. Between engine and brake booster. Injector. Blind plug. Vacuum line.
