Refrigerant Line Routing for 2018 Mercedes-Benz GLS450
No.
Part # / Description / Price
202
A/C Line O-Ring
Mercedes-Benz
Mercedes-Benz Sealing Ring
AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
202
O-Ring Mercedes-Benz
$8.75
Mercedes-Benz Profile Sealing Ring
To evaporator. Line to condenser. Condenser and connecting point 1/2". Condenser to compressor. Pipe line to refrigerant compressor. Piping to refrigerant compressor. Between evaporator and expansion valve.
205
O-Ring Mercedes-Benz
$3.20
Mercedes-Benz Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
270
Threaded Sleeve Mercedes-Benz
$9.50
Mercedes-Benz Hose line to suspension strut tower. Bracket mounting. Hydropneumatic spring leg dome. At floor. Clamp to underbody. Hose to firewall damping. To coolant line. Wiring harness. Line fastener to holder.
280
Clamp Mercedes-Benz
Mercedes-Benz Refrigerant line to body. 10 mm + 16-19 mm black. Hydropneumatic spring leg dome. 10 mm + 16-19 mm black. Line to longitudinal member. 10 MM + 16-19 MM BLACK.
330
A/C Line O-Ring Mercedes-Benz
$14.50
Mercedes-Benz Sealing Ring
SUCTION LINE 13.7X2.5 MM. 13.7X2.5
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
340
Pressure Sensor Mercedes-Benz
$159.00
Mercedes-Benz Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
362
O-Ring Mercedes-Benz
$5.50
Mercedes-Benz Profile Sealing Ring
Intake side. Upper. Expansion valve connection. Line to check valve. Piping to refrigerant compressor. Refrigerant line to connecting point and compressor 3/4". Evaporator. Refrigerant line to expansion valve .
362
Sealing Ring Mercedes-Benz
$3.60
Mercedes-Benz Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
364
O-Ring Mercedes-Benz
$17.00
Mercedes-Benz Separation point. 16.7x2.5. Engine Mounted A/C. 16.7 x 2.5mm. All Required. Roof Mounted A/C. 16.7 x 2.5mm. Refrigerant line to refrigerant line. 16.7x2.5. Suction line to compressor. 16.7x2.5. Refrigerant line connecting point. 16.7x2.5.
550
610
Spacer Mercedes-Benz
$7.25
Mercedes-Benz Bowden cable to heating feed hose. Compressor-to-condenser refrigerant line to side member. Oil pressure gauge line to speedometer drive shaft. Sensor cable 8 mm.
900
Contact Socket Housing Mercedes-Benz
$5.75
Mercedes-Benz Coolant pressure/temperature sensor b12. 3-pin mqsmodel 1: mqsslots: 3. Alarm unit h3/1. 3-pin mqsmodel 1: mqsslots: 3. Damping module at rear y53, y54. 3-pin mqsmodel 1: mqsslots: 3. Front damping module y51, y52. 3-pin mqsmodel 1: mqsslots: 3. Front door ...
