Electrical Parts Used for Trailer Coupling for 1991 Mercedes-Benz 300TE
No.
Part # / Description / Price
8
Adapter
Mercedes-Benz
Mercedes-Benz Additional stop light. Front brake lining wear indicator plug-adapter. Seat heater feed-in. Seat adjuster feed-in. Independent heating. Lower part. Speed signal. From plug connection to stop light switch. Fan. To 014 545 04 28.
14
Adapter Mercedes-Benz
Mercedes-Benz From cable harness plug-connection to tail lamp plug-connection. Seat adjuster feed-in plug-adapter. 6-pole.
17
Receptacle Mercedes-Benz
Mercedes-Benz To 000 821 24 25. To 012 545 46 28. 0.75mm2. To 000 821 19 26. 0,75 mm2. 4 mm (to 013 545 89 28). 4.0 mm.
23
Housing Upper Part Mercedes-Benz
MSRP $3.20
$3.20
Mercedes-Benz To 009 545 78 28. To 009 545 80 28. Pin bushing housing 6-polig. To 006 545 08 28. To 006 545 78 28 (asr). 6-pole. To 006 545 80 28,123 545 06 28. (plug upper part).
26
Contact Pin Mercedes-Benz
MSRP $2.40
$2.40
Mercedes-Benz 4.0 MM. 4.0 MM2 RK4Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 4.0Release tool: W220 589 01 99 52. TO 009 545 53 28/56 28. 4.0 MM2 RK4Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: R ...
27
Receptacle Housing Mercedes-Benz
Mercedes-Benz Sensor. Instrument cluster. On-board computer keyboard. Final controlling element. 8-pole. Control unit. Belt warning device. Tell-tale lamp.
29
Contact Socket Mercedes-Benz
MSRP $3.40
$3.40
Mercedes-Benz 2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...
30
Sealing Boot Mercedes-Benz
MSRP $6.00
$6.00
Mercedes-Benz Pipe line thru fire wall. In firewall, for refilling hose. In firewall, for subsequent filling hose. Pipeline. Piping.
38
Receptacle Housing Mercedes-Benz
MSRP $8.75
$8.75
Mercedes-Benz Automatic transmission shift-pointincrease relay. 6-pin. Relay for "locking completed" feedback. 6-pin. Engine shut-off relay. 6-pin. Intake manifold heating relay. 6-pole. 6-pin. Relay. 6-pole to 126 820 40 17,56 15. 6-pin. Air blow-in relay. 6-pin. Seat adjuster relay. 6-pin.
47
Housing Upper Part Mercedes-Benz
MSRP $2.70
$2.70
Mercedes-Benz To 008 545 20 28,011 545 10 28. Rear fuel pump cable harness plugconnection.
50
Contact Socket Mercedes-Benz
MSRP $3.40
$3.40
Mercedes-Benz 4,0 MM. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52. TO 008 545 08 28,000 821 22 26. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52.
56
Relay Mercedes-Benz
MSRP $92.00
$92.00
Mercedes-Benz Blinker/hazard-warng.-l.sender units, heated rear pane,wiper,trailer coupl. (time relay).
71
Nut Mercedes-Benz
Mercedes-Benz M8-10. Wiper linkage to motor drive rod. To bearing m8. Bracket to wheelhouse. Horn to stiffening. Bracket to spring dome. Triple gearing to height adjustment.
83
92
Clamp Mercedes-Benz
Mercedes-Benz Rear door contact branch-off to central pillar. 27.8 x 50.0 mm. Electric cable to side member. 27.8 x 50.0 mm. Window regulator cable harness to side member. 27.8 x 50.0 mm. Electric cable to wheel arch. 27.8 x 50.0 mm. Electric cable to tailgate. 27.8 x 50.0 mm. Plug-socket cable to frame. 27.8 x 50.0 mm. 22,75mm. 27.8 x 50.0 mm.
104
Screw Mercedes-Benz
MSRP $2.90
$2.90
Mercedes-Benz Bracket to whelhouse flange. Bracket to wheelhouse. Ground cable to rear pillar. Bracket to antenna.
128
