Parking Brake for 1992 Mercedes-Benz 500 E
No.
Part # / Description / Price
29
Hexagon Head Bolt
Mercedes-Benz
$4.20
Mercedes-Benz Screw
Bracket to pedal assembly. Steering lock to steering column jacket tube. Master cylinder to pedal assembly.
32
Cover Mercedes-Benz
$11.50
Mercedes-Benz Pedal to 163 420 02 84/03 84. On foot-operated parking brake. Pedal to 208 420 00 84.
35
Hexagon Head Bolt Mercedes-Benz
$6.00
Mercedes-Benz Screw
M8X22
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Foot-operated parking brake to front panel pillar. Fastening, foot-operated parking brake. Distributor to bracket. Foot operated parking brake to fire wall m 8x22. Foot operated parking brake to fire wall m8 x 22.
59
Hexalobular Bolt Mercedes-Benz
$3.50
Mercedes-Benz Screw
Mounting parts. 5x12 mm. Bracket mounting. 5x12 mm. Left. 5x12 mm.
71
Hose Mercedes-Benz
Mercedes-Benz Front brake cable to parking brake. Brake cable to brake lever. For ground cable, fuel pump order by the meter. 12 mm. Front brake cable 15mm. On wire spiral, choke cable order by the meter.
74
Fastening Clamp Mercedes-Benz
Mercedes-Benz Front brake cable to fire wall. Brake control cable to tunnel. Front cable to firewall. On fire wall. At refrigerant line,for rear space heating. Cable harness to wiper motor plug. Front brake cable to tunnel. Hose to body.
80
Hexagon Head Bolt Mercedes-Benz
$2.40
Mercedes-Benz Shackle mounting. M8X30
Diameter: 8mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. At support. Instrument panel to left / right A-pillar and wind deflector M 8X30. Seat framework to backrest. Child's seat mounting. Child seat safety catch. Left and right outer guard plate to rear panel. Rear m8x30. Crossmember to a-pillar.
83
Screw Mercedes-Benz
$3.50
Mercedes-Benz Front brake cable to brake readjustment. M8. Brake cable to clamp. Front brake cable to parking brake. Hand brake to tunnel.
