Cockpit Cable Harness for 1998 Mercedes-Benz C230

Cockpit cable harness used with automatic heating with dust filter.

Cockpit cable harness used with automatic air conditioner.

Cockpit cable harness used with automatic heating with dust filter.

Cockpit cable harness used with automatic heating with dust filter.

(addit. Cable harness) for air conditioner;only with subsequent installation.

Instrument cluster,24-pole.

To 001 545 06 40.

Buzzer contact;2-pole. 2-pin. Central locking system. 2-pin. Evaporator temperature sensor. 2-pin. Solenoid valve,bipolar. 2-pin. Temperature sensor;2-pole. 2-pin. Heating water valve,temperature sensor,electro-magnet valves;bipolar. 2-pin.

At lf outlet. 3-pin. 3-pole. 3-pin. Heat exchanger temperature sensor 3 polig. 3-pin. Temperature sensor,heat exchanger, three-pin. 3-pin. Valve strip. 3-pin.

Amplifier. 4-pin. Cd changer. 4-pin. Info module asr. 4-pin. Function control 4-matic. 4-pin. Timer,heater. 4-pin. Radio current supply. 4-pin. Additional heater preset time switch. 6-pole. 4-pin. 3-pole. 4-pin.

Light switch. To 012 545 74 28. To 014 545 64 28.

Relay cluster.

Heated rear pane switch. Headrest switch. Undercarriage change-over switch. Level switch. Engine residual heat utilization switch.

Round Receptacle

2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...

Dome lighting. 8-pin. Steering column jacket tube adjustment switch. 8-pin. Separation point ads. 8-pin. Dome lamp,front. 8-pin. Plug connection. 8-pin. Steering column electrically adjustable 8-polig. 8-pin. Steering column adjustment motor 8-polig. 8-pin. Tempomat switch. 8-pin.

Speed sensor plug-connection,rear axle. 8-pin. Door separation point,b-pillar. 8-pin. Plug connection for tail lamp wiring harness,eight-pin. 8-pin. Tail lamp cable harness plugconnection 8 polig. 8-pin. Engine compartment/cockpit connector. 8-pin. Plug connection,speed sender unit 8 polig. 8-pin. Soft top. 8-pin.

Part. Point diagnostics wiring harness. Engine cable harness plug-connection 12 polig. Plug connection of engine cable harness,12-pole.

Transmission shifting lock. 2-pin. Parking interlock. 2-pin. Back-up lock and cruise control. 2-pin. Plug connection,entrance illumination,doors front left and right 2-polig. 2-pin.

Combination switch plug-connection.

0,5-1,0 MM2, TO 032 545 19 28. 0.5-1.0 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO A 029 545 19 28. 0.5-1.0 MM2 ...

Automatic transmission shift-pointincrease relay. 6-pin. Relay for "locking completed" feedback. 6-pin. Engine shut-off relay. 6-pin. Intake manifold heating relay. 6-pole. 6-pin. Relay. 6-pole to 126 820 40 17,56 15. 6-pin. Air blow-in relay. 6-pin. Seat adjuster relay. 6-pin.

Ignition/starting switch. 7-pin.

Engine cable harness plug-connection. 3-pin. Tail lamp cable harness plugconnection 3 polig. 3-pin. Heating water valve. 3-pin. Duo-water valve. 3-pin.

Front loudspeaker. 4-pin. Wiper motor. 4-pin. Circulating air switch. 4-pole. 4-pin. Pneumatic control unit. 4-pin. Air recirculation switch. 4-pin.

Receptacle Housing

Door separation point. Automatic heating operating unit. 12-pole.

Operating unit of automatic heating with dust filter/circulating air.

Valve strip. 9-pin jpt. Door separation point,a-pillar. 9-pin jpt. Tv/tuner antenna connector x1/28,. 9-pin jpt.

Contact Spring

1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.

Metering pump to 116 540 01 81. Cold start valve plug.

Plug socket 12v. Pass. Left rear reading lamp. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Additional heater control unit. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Radio connection x58/2. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Front interior socket ...

At hazard warning light switch to 202 820 78 10. S 6/1.

756. 1.0-2.5 mm2 ff6.3. Radio. 1.0-2.5 mm2 ff6.3. Engine hood. 1.0-2.5 mm2 ff6.3. Parking brake switch. 1.0-2.5 mm2 ff6.3.

Operating unit of tempmatik/automatic air conditioner 29polig. 29-pin. Operating unit of tempmatik/automatic air conditioner code 580/581, 29 polig. 29-pin. To 000 545 34 30. 000 545 35 30. 29-pin.

Operating unit of tempmatik/automatic air conditioner. Control module air conditioning.

0,35MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Release tool: W220 589 01 99 55. 0,5-1,0 MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Relea ...

0.75mm2. 0.75 MM2
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.

Plug connection for tail lamp wiring harness,four-pin. 4-pin. Intermediate connector tail lamp wiring harness. 4-pin. Frame plug-connection. 4-pin. Outside rearview mirror plug connection. 4-pin.

Plug connection 4 polig, (motorraum/cockpit). 4-pin. Tail lamp cable harness plugconnection. 4-pin. Engine plug connection cockpit. 4-pin.

Ashtray lighting in the rear. 2-pin mqs. Ignition lock. 2-pin mqs.

Plug Socket

"sam" control unit rear. 14-pin mqs
model 1: mqs
slots: 14. Light rotary switch. 14-pin mqs
model 1: mqs
slots: 14. Drive unit control unit n145*1. 14-pin mqs
model 1: mqs
slots: 14. Control unit multi-contour backrest. 14-pin mqs
model 1: mqs
slots: 14. Control unit, electronic ignition lock. 14-pin mqs
model 1: mqs
slots: 14.

Gear recognition S16/10. 8-PIN. Gear recognition switch s17/10. 8-pin. Outside rearview mirror code b. 8-pin. Sam control unit. 8-pin. Relay cluster. 8-pin.

Electronic ignition switch controlunit n73. 6-pin. Ignition/starter switch, 6-pin. 6-pin. Control unit, electronic ignition lock. 6-pin. Starting ignition switch n73. 6-pin.

Combination switch,6-pole. 6-pin. Control unit. 6-pin. Combination switch plug-connection. 6-pin.

Crimp Tml. Pin Contact

X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...

Fuse and relay box,driver 4 polig. 4-pin. Front fuse and relay box. 4-pin. Srb/fahrer, c1. 4-pin.

Tin-plated. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. GLOVE COMPARTMENT LIGHTING E13/1. 1.5 MM2 WDF2Leitungsquerschnitt Min/Max: 1,5mm2Oberflächenschutz PINs: SnModel 1: WDF2. CIGAR LIGHTER R3. 1.5 MM2 WDF2Le ...

Bipolar fuse box "m".

Range of delivery for subsequent installation.

Fuse box "w".

Fuse box "m".
