Frame Floor Unit Main Cable Harness for 1999 Mercedes-Benz C280
No.
Part # / Description / Price
5
Electric Line
Mercedes-Benz
Mercedes-Benz Anti-theft warning syst. With infrared locking system and mirror adjustment.
8
Electric Line Mercedes-Benz
$28.50
Mercedes-Benz Wiring Harness
Belt locking retractor. Belt tensioner squib. Co-driver's air bag primer pellet.
20
Receptacle Housing Mercedes-Benz
Mercedes-Benz Dome lighting. 8-pin. Steering column jacket tube adjustment switch. 8-pin. Separation point ads. 8-pin. Dome lamp,front. 8-pin. Plug connection. 8-pin. Steering column electrically adjustable 8-polig. 8-pin. Steering column adjustment motor 8-polig. 8-pin. Tempomat switch. 8-pin.
30
Contact Socket Mercedes-Benz
$2.90
Mercedes-Benz 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...
35
Receptacle Housing Mercedes-Benz
Mercedes-Benz Central locking mechanism interior control. Conjunction with parking aid switch. Comfort/sport change-over trimmer plug 5-polig. Inner central locking mechanism switch.
37
Receptacle Housing Mercedes-Benz
Mercedes-Benz Mirror adjustment switch. 8-pole. 8-pin. Rearview mirror glare control switch. 8-pin. Autside rearview mirror adjustment switch. 8-pin.
38
Contact Socket Mercedes-Benz
$2.70
Mercedes-Benz 2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...
40
Contact Socket Mercedes-Benz
$5.25
Mercedes-Benz 0.75mm2. 0.75 MM2
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
42
Pin Bushing Housing Mercedes-Benz
Mercedes-Benz Tail lamp cable harness plugconnection. Rear fuel pump cable harness plugconnection.
45
Plug Housing Mercedes-Benz
Mercedes-Benz Warning buzzer. Language control system. Four-pin. Cockpit cable harness plug-connection. Engine cable harness plug-connection. Tempomat(cruise control) plug-connect.
47
Receptacle Housing Mercedes-Benz
Mercedes-Benz Rear speed sensor. Sensor cable. Engine/heater-operation cable-harness plug-connection, 6-pole.
48
Contact Pin Mercedes-Benz
$7.75
Mercedes-Benz To 016 545 01 28. 0.35-2.5 mm2 rk2.5. To 020 545 49 28. 0.35-2.5 mm2 rk2.5. 0,5-1,0mm2, to 023 545 52 28. 0.35-2.5 mm2 rk2.5. Only used with acceleration skid control (asr). 0.35-2.5 mm2 rk2.5. (lock angle sensor) 4.0 mm. 0.35-2.5 mm2 rk2.5. 2,5mm. 0.35-2.5 mm2 rk2.5. 0.25-2.5 mm. 0.35-2.5 mm2 rk2.5.
50
Housing Upper Part Mercedes-Benz
$3.20
Mercedes-Benz To 009 545 78 28. To 009 545 80 28. Pin bushing housing 6-polig. To 006 545 08 28. To 006 545 78 28 (asr). 6-pole. To 006 545 80 28,123 545 06 28. (plug upper part).
52
Housing Mercedes-Benz
$3.60
Mercedes-Benz Breakdown/information button conn. Glove compartment. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60. Mobile phone disconnecting point x39/37. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60. Plug connection, group of switches, centre console. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60. Contact carrier to 001 545 59 40. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60.
75
Round Receptacle Mercedes-Benz
$8.25
Mercedes-Benz 1MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. 1,0 MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. DATA LI ...
76
Plug Mercedes-Benz
Mercedes-Benz Loudspeaker connection. Front loudspeaker. To 000 546 83 40. On plug connection,wiper motor. Loudspeaker cable.
82
Contact Spring Mercedes-Benz
Mercedes-Benz WINDSHIELD WASHER NOZZLE HEATINGLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: PLModel 2: 6.3. DOOR CONTACTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: PLModel 2: 6.3. TO 124 540 21 81Le ...
95
Female Spade Connector Mercedes-Benz
Mercedes-Benz Hand-brake-control switch. Trunk lighting. Parking brake switch to 004 545 20 26. Offset. 0.5-1.5mm2. Parking brake control.
105
Insulating Sleeve Mercedes-Benz
Mercedes-Benz To 000 546 83 40. To 000 546 79 40. To 000 546 583 40. Charge control. Electric cable to pressure switch. Low pressure switch.
115
Contact Spring Mercedes-Benz
$3.90
Mercedes-Benz Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
115
Spring Retaining Pin Mercedes-Benz
$4.00
Mercedes-Benz Contact Spring
0.35.1.0 mm2. 1.5-2.5 mm2,1 polig. Unipolar. 1.5-2.5 mm2, 1polig. 1.5-2.5mm2.
115
Contact Spring Mercedes-Benz
$4.90
Mercedes-Benz Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
121
Receptacle Housing Mercedes-Benz
$5.50
Mercedes-Benz Headlamp cleaning system pump in container. 2 pin jpt. Metering pump. 2 pin jpt. Windshield washer pump;2-pole. 2 pin jpt. As required. 2 pin jpt. Valve to activated charcoal filter y58/1. 2 pin jpt.
122
Protective Cap Mercedes-Benz
Mercedes-Benz To 140 545 35 28. To 116 540 10 81. To a1165400181. To 116 540 01 81. Fuel gauge.
123
Electric Coupling Mercedes-Benz
Mercedes-Benz Loudspeaker connection cod.b. 8-POLE. 8-PIN JPTModel 1: JPT / MDK3Model 2: 3Slots: 8Release tool: W000 589 13 99 30. RADIO "B". 8-PIN JPTModel 1: JPT / MDK3Model 2: 3Slots: 8Release tool: W000 589 13 99 30. Inboard cable harness plug-connection. 8-pin jptm ...
123
Coupling, Mechanical Mercedes-Benz
$4.50
Mercedes-Benz Power connection cod.a. Audio 10/30 radio. 8-pin jpt. Radio "a". 8-pin jpt. Cockpit cable harness plug-connection. 8-pin jpt. Operating unit a2. 8-pin jpt.
125
Contact Spring Mercedes-Benz
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
125
Spring Retaining Pin Mercedes-Benz
$3.90
Mercedes-Benz Contact Spring
1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
128
Plug Mercedes-Benz
Mercedes-Benz Door separation point,b-pillar. 8-pin. Plug connection for tail lamp wiring harness,eight-pin. 8-pin. Oxygen sensor separation point. 8-pin. To engine plug connection / cockpit control module me in module box. 8-pin. Engine cable harness plug-connection to frame mounted cable harness. 8-pin. Plug connection,speed sender unit. 8-pin.
131
Plug Housing Mercedes-Benz
Mercedes-Benz Folding top plug-connection. 2-pin. Adaptive damping system plugconnection. 2-pin. Door separation point,a-pillar. 2-pin.
131
Plug Housing Mercedes-Benz
Mercedes-Benz Tail lamp cable harness and fuel pump cable "a". 4-pin rk2.5. Plug connection engine/body. 4-pin rk2.5. Plug connection for tail lamp wiring harness,four-pin. 4-pin rk2.5. Diagnosis box plug connection 4-polig. 4-pin rk2.5. Door separation point. 4-pin rk2.5. From light range regulator to rear axle 4-polig. 4-pin rk2.5.
134
Contact Pin Mercedes-Benz
$2.70
Mercedes-Benz 207. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. RPM SENSOR 0,5-1,0mm2. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. 0,5-1,0 MM. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5.
140
Crimp Tml Pin Contact Mercedes-Benz
$2.80
Mercedes-Benz Crimp Tml. Pin Contact
X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
143
Clamp Mercedes-Benz
Mercedes-Benz Belt lock to seat rail. Cable harness to roof rail. Electric cable to bracket. At bracket. Blower regulator plug to air conditioner case. Cross member below front seat. Electric cable to rear lid. Test plug. Rear lid lock.
155
Hexalobular Screw Mercedes-Benz
$3.00
Mercedes-Benz Screw
Door separation point coupler to a-pillar. M5X25
Diameter: 5mm
Strength / hardness class: 4.8
Thread code letter: M
Thread pitch: 1mm. Pump,filter & fuel accumulator to bracket. At bracket. Cover to housing with tray. Connector to instrument panel reinforcement.
No.
Part # / Description / Price
12
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Air bag cable harness plug-connection. 2-pin. Door separation point,b-pillar. 2-pin. Intermediate connector, airbag. 2-pin. Primer pellet. 2-pin. Plug connection contact spiral airbag. 2-pin. Seat contacting. 2-pin.
17
Receptacle Housing Mercedes-Benz
Mercedes-Benz Driver's belt lock. Belt lock branch-off. Seat contacting. Belt lock switch. Seat belt buckle. On contact strip,seat.
28
Receptacle Housing Mercedes-Benz
Mercedes-Benz Multiple function strip. Seat adjustment control unit. Tail lamp cable harness plug-connection, 6-pole. Module box cable-harness plugconnection. Rear speed sensor. Sliding roof switch. Electric sliding roof. Intermediate plug connection,diagnosis / tail lamp cable harness.
29
Receptacle Housing Mercedes-Benz
Mercedes-Benz Co-driver's seat. 4-pin. Multi-point plug front pass. Side. 4-pin. Seat multiple plug. 4-pin. Seat occupation recognition 4 polig. 4-pin. At coupler strip. 4-pin.
50
Receptacle Housing Mercedes-Benz
$8.75
Mercedes-Benz Automatic transmission shift-pointincrease relay. 6-pin. Relay for "locking completed" feedback. 6-pin. Engine shut-off relay. 6-pin. Intake manifold heating relay. 6-pole. 6-pin. Relay. 6-pole to 126 820 40 17,56 15. 6-pin. Air blow-in relay. 6-pin. Seat adjuster relay. 6-pin.
54
Receptacle Housing Mercedes-Benz
Mercedes-Benz Inside rearview mirror. 8-pin. Interior mirror. 8-pin. Rearview mirror adjustment. 8-pin. Rearview mirror glare control switch. 8-pin. Adjustable outside rearview mirror. 8-pin. Automatically dipping inside rear view mirror. 8-pin. Mirror innen. 8-pin. Automatic mirror glare control. 8-pin.
55
Cap Mercedes-Benz
$6.75
Mercedes-Benz Housing adjustment. To a 017 545 56 28 (a50). To 017 545 56 28,022 545 42 28.
80
Receptacle Housing Mercedes-Benz
Mercedes-Benz Operating unit a2. 10-pin jpt. Radio 10-polig. 10-pin jpt. Radio set,10-pole. 10-pin jpt.
83
Contact Spring Mercedes-Benz
$5.00
Mercedes-Benz 0,35MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Release tool: W220 589 01 99 55. 0,5-1,0 MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Relea ...
83
Spring Retaining Pin Mercedes-Benz
$3.90
Mercedes-Benz Contact Spring
1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
83
Plug Mercedes-Benz
Mercedes-Benz Transfer case S97/5,. 6-PIN E95. Fold-away outside rearview mirror switch. 6-pin e95.
118
Receptacle Housing Mercedes-Benz
$6.00
Mercedes-Benz Exhaust gas aftertreatment k27/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Restraint system k40/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. K74. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Relay, stop lamp suppression 9 ...
121
Receptacle Housing Mercedes-Benz
$4.50
Mercedes-Benz Operating unit. 18-pin mqs
model 1: mqs
slots: 18. Automatic air conditioner. 18-pin mqs
model 1: mqs
slots: 18. Central locking mechanism pump. 18-pin mqs
model 1: mqs
slots: 18. Control unit door. 18-pin mqs
model 1: mqs
slots: 18. Control unit pse. 18-pin mqs
model 1: mqs
slots: 18. Radio navigation control unit 18-polig. 18-pin mqs
model 1: mqs
slots: 18.
126
Plug Mercedes-Benz
Mercedes-Benz Rpm sensor. 8-pin. To engine plug connection / cockpit control module me in module box. 8-pin. Diagnosis box plug connection 8-polig. 8-pin. Control unit box/engine sep. Point. 8-pin. Tail lamp cable harness plugconnection. 8-pin.
131
Contact Socket Mercedes-Benz
$2.70
Mercedes-Benz Round Receptacle
2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...
No.
Part # / Description / Price
6
Electric Line Mercedes-Benz
Mercedes-Benz Repair Kit
Side airbag repair solution. 2-pinmodel 1: rkmodel 2: 1slots: 2. Sidebag, left r12/9. 2-pinmodel 1: rkmodel 2: 1slots: 2. Front passenger airbag squib. 2-PINModel 1: RKModel 2: 1Slots: 2. Front passenger airbag, yellow. 2-pinmodel 1: rkmodel 2: 1slots: 2. ...
10
50
Plug Housing Mercedes-Benz
Mercedes-Benz Rear fuel pump cable harness plugconnection. Multiple function strip. Tail lamp cable harness plug-connection, 6-pole. Overheat warning indicator plugconnection. Engine cable harness plug-connection rba. Tempomat switch.
55
Plug Mercedes-Benz
Mercedes-Benz Declutching-start/back-up-light switch plug connection. Engine cable harness plug-connection. Tail lamp cable harness plugconnection.
55
Receptacle Housing Mercedes-Benz
Mercedes-Benz Rpm sensor "c". 4-pin. Tail lamp cable harness plugconnection. 4-pin. Cockpit cable harness plug-connection. 4-pin. Electronic accelerator/ snow chain switch. 4-pin.
60
Contact Pin Mercedes-Benz
$1.70
Mercedes-Benz Partition point pri. Veh. Warn. Sig. X41/4. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: DIAModel 2: 2.5. DOOR SEPARATION POINT 1,0-2,5 MM2. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberfl ...
75
Contact Spring Mercedes-Benz
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
82
82
Receptacle Housing Mercedes-Benz
$7.25
Mercedes-Benz Plug connection roof mounted operating unit. 28-pin mqs;. Part 2 to a000 545 93 03. 28-pin mqs;.
84
Cover Cap Mercedes-Benz
Mercedes-Benz Door separation point,a-pillar to 202 540 15 81. Door separation point,a-pillar to 202 545 15 81.
84
86
88
Cap Mercedes-Benz
Mercedes-Benz Door separation point,b-pillar to 202 540 16 81. Door separation point,b-pillar to 2025401681.
94
96
Socket Mercedes-Benz
Mercedes-Benz Lighting of gear indicator. Lamp control. Tell-tale lamp airbag. Windshield-washer-fluid control. Shift gate illumination. Bipolar. Tell-tale lamp abs/asr. Pre-glow indicator. Tell-tale lamp 4-matic. (oxygen sensor exchange indicator).
104
Screw Mercedes-Benz
Mercedes-Benz M5x8. Door separation point coupler to b-pillar. Control unit to bracket. Control module mounting.
