Burglary Alarm System and Infrared Closing System for 1999 Mercedes-Benz C280
No.
Part # / Description / Price
17
Receptacle Housing
Mercedes-Benz
Mercedes-Benz Inside rearview mirror. 8-pin. Interior mirror. 8-pin. Rearview mirror adjustment. 8-pin. Rearview mirror glare control switch. 8-pin. Adjustable outside rearview mirror. 8-pin. Automatically dipping inside rear view mirror. 8-pin. Mirror innen. 8-pin. Automatic mirror glare control. 8-pin.
19
Cap Mercedes-Benz
$6.75
Mercedes-Benz Housing adjustment. To a 017 545 56 28 (a50). To 017 545 56 28,022 545 42 28.
21
Housing Mercedes-Benz
$3.60
Mercedes-Benz Plug Housing
Breakdown/information button conn. Glove compartment. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60. Mobile phone disconnecting point x39/37. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60. Plug connection, group of switches, centre console. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60. Contact carrier to 001 545 59 40. 10-pin mqs
model 1: mqs
slots: 10
release tool: w220 589 01 99 60.
28
Receptacle Housing Mercedes-Benz
$4.50
Mercedes-Benz Operating unit. 18-pin mqs
model 1: mqs
slots: 18. Automatic air conditioner. 18-pin mqs
model 1: mqs
slots: 18. Central locking mechanism pump. 18-pin mqs
model 1: mqs
slots: 18. Control unit door. 18-pin mqs
model 1: mqs
slots: 18. Control unit pse. 18-pin mqs
model 1: mqs
slots: 18. Radio navigation control unit 18-polig. 18-pin mqs
model 1: mqs
slots: 18.
33
Round Receptacle Mercedes-Benz
$8.25
Mercedes-Benz 1MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. 1,0 MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. DATA LI ...
33
Contact Socket Mercedes-Benz
$5.25
Mercedes-Benz 0.75mm2. 0.75 MM2
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
37
Receptacle Housing Mercedes-Benz
Mercedes-Benz Temperature switch. Plug connection for cable harness of speakers in instrument panel. Multiple function strip. Cable-harness plug-connection, 6-pole. Interior safeguard control unit. Adjustable steering column. 6-polig.
43
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Air bag cable harness plug-connection. 2-pin. Door separation point,b-pillar. 2-pin. Intermediate connector, airbag. 2-pin. Primer pellet. 2-pin. Plug connection contact spiral airbag. 2-pin. Seat contacting. 2-pin.
49
Contact Socket Mercedes-Benz
$2.90
Mercedes-Benz 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...
55
Housing Upper Part Mercedes-Benz
$3.20
Mercedes-Benz To 009 545 78 28. To 009 545 80 28. Pin bushing housing 6-polig. To 006 545 08 28. To 006 545 78 28 (asr). 6-pole. To 006 545 80 28,123 545 06 28. (plug upper part).
61
Plug Housing Mercedes-Benz
Mercedes-Benz Warning buzzer. Language control system. Four-pin. Cockpit cable harness plug-connection. Engine cable harness plug-connection. Tempomat(cruise control) plug-connect.
64
Contact Pin Mercedes-Benz
$7.75
Mercedes-Benz To 016 545 01 28. 0.35-2.5 mm2 rk2.5. To 020 545 49 28. 0.35-2.5 mm2 rk2.5. 0,5-1,0mm2, to 023 545 52 28. 0.35-2.5 mm2 rk2.5. Only used with acceleration skid control (asr). 0.35-2.5 mm2 rk2.5. (lock angle sensor) 4.0 mm. 0.35-2.5 mm2 rk2.5. 2,5mm. 0.35-2.5 mm2 rk2.5. 0.25-2.5 mm. 0.35-2.5 mm2 rk2.5.
82
Plug Mercedes-Benz
Mercedes-Benz Control unit of infrared remote control. Control unit for infrared remote control,two-pin.
88
Receptacle Housing Mercedes-Benz
$7.25
Mercedes-Benz Plug connection roof mounted operating unit. 28-pin mqs;. Part 2 to a000 545 93 03. 28-pin mqs;.
94
97
Electric Coupling Mercedes-Benz
Mercedes-Benz Loudspeaker connection cod.b. 8-POLE. 8-PIN JPTModel 1: JPT / MDK3Model 2: 3Slots: 8Release tool: W000 589 13 99 30. RADIO "B". 8-PIN JPTModel 1: JPT / MDK3Model 2: 3Slots: 8Release tool: W000 589 13 99 30. Inboard cable harness plug-connection. 8-pin jptm ...
97
Coupling, Mechanical Mercedes-Benz
$4.50
Mercedes-Benz Power connection cod.a. Audio 10/30 radio. 8-pin jpt. Radio "a". 8-pin jpt. Cockpit cable harness plug-connection. 8-pin jpt. Operating unit a2. 8-pin jpt.
100
Receptacle Housing Mercedes-Benz
$5.50
Mercedes-Benz Headlamp cleaning system pump in container. 2 pin jpt. Metering pump. 2 pin jpt. Windshield washer pump;2-pole. 2 pin jpt. As required. 2 pin jpt. Valve to activated charcoal filter y58/1. 2 pin jpt.
103
Protective Cap Mercedes-Benz
Mercedes-Benz To 140 545 35 28. To 116 540 10 81. To a1165400181. To 116 540 01 81. Fuel gauge.
109
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Burglary alarm system control unit. 33-pin jpt. Multi-function control module for spec. Purp. Veh. N26/14. 33-pin jpt.
112
Crimp Tml Pin Contact Mercedes-Benz
$2.80
Mercedes-Benz Crimp Tml. Pin Contact
X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
112
Contact Spring Mercedes-Benz
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
115
Receptacle Housing Mercedes-Benz
Mercedes-Benz Dome lamp;3-pole. 3-pin. Cigar lighter. 3-pin. Rear dome lamp. 3-pin.
124
Spring Retaining Pin Mercedes-Benz
$4.00
Mercedes-Benz Contact Spring
0.35.1.0 mm2. 1.5-2.5 mm2,1 polig. Unipolar. 1.5-2.5 mm2, 1polig. 1.5-2.5mm2.
130
Contact Spring Mercedes-Benz
Mercedes-Benz WINDSHIELD WASHER NOZZLE HEATINGLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: PLModel 2: 6.3. DOOR CONTACTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: PLModel 2: 6.3. TO 124 540 21 81Le ...
133
Plug Mercedes-Benz
Mercedes-Benz Door separation point,b-pillar. 8-pin. Plug connection for tail lamp wiring harness,eight-pin. 8-pin. Oxygen sensor separation point. 8-pin. To engine plug connection / cockpit control module me in module box. 8-pin. Engine cable harness plug-connection to frame mounted cable harness. 8-pin. Plug connection,speed sender unit. 8-pin.
136
Plug Housing Mercedes-Benz
Mercedes-Benz Folding top plug-connection. 2-pin. Adaptive damping system plugconnection. 2-pin. Door separation point,a-pillar. 2-pin.
139
Receptacle Housing Mercedes-Benz
Mercedes-Benz Rpm sensor "c". 4-pin. Tail lamp cable harness plugconnection. 4-pin. Cockpit cable harness plug-connection. 4-pin. Electronic accelerator/ snow chain switch. 4-pin.
142
Plug Housing Mercedes-Benz
Mercedes-Benz Tail lamp cable harness and fuel pump cable "a". 4-pin rk2.5. Plug connection engine/body. 4-pin rk2.5. Plug connection for tail lamp wiring harness,four-pin. 4-pin rk2.5. Diagnosis box plug connection 4-polig. 4-pin rk2.5. Door separation point. 4-pin rk2.5. From light range regulator to rear axle 4-polig. 4-pin rk2.5.
145
Contact Pin Mercedes-Benz
$1.70
Mercedes-Benz Partition point pri. Veh. Warn. Sig. X41/4. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: DIAModel 2: 2.5. DOOR SEPARATION POINT 1,0-2,5 MM2. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberfl ...
145
Contact Pin Mercedes-Benz
$2.70
Mercedes-Benz 207. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. RPM SENSOR 0,5-1,0mm2. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. 0,5-1,0 MM. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5.
148
Receptacle Housing Mercedes-Benz
$6.00
Mercedes-Benz Exhaust gas aftertreatment k27/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Restraint system k40/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. K74. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Relay, stop lamp suppression 9 ...
151
Contact Spring Mercedes-Benz
Mercedes-Benz 0,5-1,0 MM2. 0.5-1.0 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: +
Model 1: JPT
Model 2: 2.8.
163
Receptacle Housing Mercedes-Benz
Mercedes-Benz Accelerator pedal switch. 4-pin. Warning buzzer. 4-pin. Oxygen sensor plug connection. 4-pin. Push to talk. 4-pin.
172
Housing Upper Part Mercedes-Benz
$2.70
Mercedes-Benz To 008 545 20 28,011 545 10 28. Rear fuel pump cable harness plugconnection.
175
Plug Pin Mercedes-Benz
Mercedes-Benz To 011 545 10 28. 4.0 mm. To 009 545 14 28. Tempomat(cruise control) plug-connect. To 012 545 84 28. 4.0mm2.
182
Alarm Siren Mercedes-Benz
Mercedes-Benz Alarm Equipment
Siren. Behind left wheelhouse. Anti-theft alarm h3/1. Antitheft warning system and anti-tow-away system.
Not For Sale
191
Screw Mercedes-Benz
$50.00
Mercedes-Benz M8x16. Siren to bracket. Alarm unit fastening to bracket. Bracket to body shell. Bracket mounting. Locking screw (siren).
193
Wiper Arm Nut Mercedes-Benz
$3.40
Mercedes-Benz Hexagon Nut
Master cylinder to brake booster. Rear bumper to rear body panel cross member. Electric cable to alternator. Pedal assembly to fire wall. Front bumper to cross member. Armrest to backrest. Bracket to bumper. Left stiffening to right stiffening. On front door,bottom.
211
Plug Mercedes-Benz
$4.00
Mercedes-Benz Burglary alarm system control unit. 4-pin jpt. Control unit 4 polig. 4-pin jpt. Belt feeder,left a10. 4-pin jpt. Door control unit. 4-pin jpt.
214
Spring Retaining Pin Mercedes-Benz
$3.90
Mercedes-Benz Contact Spring
1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
229
Socket-Outlet Mercedes-Benz
Mercedes-Benz Engine hood switch anti-theft alarm system. 2-pin. Engine hood contact switch 2-polig. 2-pin.
259
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Control unit towing protection. 6-pin. Anti-theft alarm system (ata) inclination sensor. 6-pin.
262
Contact Socket Mercedes-Benz
$5.75
Mercedes-Benz 0,5-1,0 MM2, TO 032 545 19 28. 0.5-1.0 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO A 029 545 19 28. 0.5-1.0 MM2 ...
265
Receptacle Housing Mercedes-Benz
Mercedes-Benz Mode indicator switch anti-theft alarm system. 3-pin. Inner central locking mechanism switch. 3-pin. Burglary alarm system switch. 3-pin.
268
Contact Spring Mercedes-Benz
$5.00
Mercedes-Benz 0,35MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Release tool: W220 589 01 99 55. 0,5-1,0 MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Relea ...
286
Cap Mercedes-Benz
Mercedes-Benz Interior safeguard,left. Central pillar,left. Infrared protection of the interior.
289
Alarm Equipment Mercedes-Benz
$282.00
Mercedes-Benz Towing protection. Anti-theft alarm system (ata) inclination sensor. Towing sensor. Range of delivery for subsequent installation.
290
Electric Line Mercedes-Benz
$57.00
Mercedes-Benz Adapter cable. Adapter line. Burglary alarm system control unit. To a 203 820 27 26.
295
Spring Nut Mercedes-Benz
$2.00
Mercedes-Benz Securing
Control unit to c-pillar. Bracket to c-pillar. Anti-tow-away sensor. Bracket mounting aeg. Instrument panel to cross member. Abs control unit. Control unit to mounting plate. Bracket to wheelhouse. Electronic gas control unit. Instrument panel to knee protection pad.
