Cockpit Cable Harness for 2007 Mercedes-Benz R 500
No.
Part # / Description / Price
100
100
100
100
100
100
100
100
100
100
100
100
100
100
105
110
Electrical Wiring Harness
Mercedes-Benz
Mercedes-Benz REAR FUSE BOX 1,5-2,5 MM2. 1.5 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
110
Electric Line Mercedes-Benz
$2.70
Mercedes-Benz FUSE BOX 0.35--1.0 MM2. 1.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
115
Plug Mercedes-Benz
$7.00
Mercedes-Benz Connector, interior/engine black x25/2*2. 6-pin mcp2.8. Cockpit/interior plug connector x18. 6-pin mcp2.8. Connector, cockpit/interior, black x18. 6-pin mcp2.8. Engine compartment/interior connector x25/2. 6-pin mcp2.8.
120
Male Spade Connector Mercedes-Benz
$3.40
Mercedes-Benz 0.2-0.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 0,2-0,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
120
Male Spade Connector Mercedes-Benz
$2.50
Mercedes-Benz 1.5-2.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8.
125
150
Plug Housing, Rectangular Mercedes-Benz
Mercedes-Benz Front center bracket separation point x138/1*1. 10-pin mqs. Overhead control panel/ffs connector x25/8. 10-pin mqs. Separation point rear panel door x8/45*1. 10-pin mqs. Connector, center nozzle x122/1. 10-pin mqs.
155
Crimp Tml Pin Contact Mercedes-Benz
$2.80
Mercedes-Benz Crimp Tml. Pin Contact
X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
170
Receptacle Housing Mercedes-Benz
$5.25
Mercedes-Benz Plug socket 12v. Pass. Left rear reading lamp. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Additional heater control unit. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Radio connection x58/2. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Front interior socket ...
175
Receptacle Mercedes-Benz
$2.70
Mercedes-Benz Tin-plated. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: FFModel 2: 6.3. TO 001 545 10 28,012 545 31 28. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: ...
240
Distributor Mercedes-Benz
$37.00
Mercedes-Benz Can bus distributor x30/5. 12x2/1x3 pin. Potential distributor can c x63/4. 12x2/1x3 pin. Can bus c, right x30/19. 12x2/1x3 pin. Can c connector x63/4. 12x2/1x3 pin. Connector can databus x63/4,. 12x2/1x3 pin. Can bus c, left x30/5. 12x2/1x3 pin. Can bus c x30/18. 12x2/1x3 pin. Can bus c, left x63/4. 12x2/1x3 pin. Voltage distributor, can bus 27-pin. 12x2/1x3 pin.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Steering column electrically adjustable x4/39-m20/1+2. On steering column jacket tube.
