Propeller Shaft for 2007 Mercedes-Benz R500
No.
Part # / Description / Price
15
Hexalobular Screw
Mercedes-Benz
$12.50
Mercedes-Benz Propeller shaft to transfer case. M10X45
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Propeller shaft to rear axle. Propeller shaft to front axle differential. Front propeller shaft m10x45.
45
Shim Mercedes-Benz
Mercedes-Benz Propeller shaft to front axle differential 3,0 MM
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 3mm. TO FRONT AXLE GEAR 16X3,0
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 3mm.
45
Shim Mercedes-Benz
Mercedes-Benz Propeller shaft to front axle differential 2,0 MM
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 2mm. TO FRONT AXLE GEAR 16X2,0
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 2mm.
45
Shim Mercedes-Benz
$4.20
Mercedes-Benz Propeller shaft to front axle differential 1,0 MM
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 1mm. TO FRONT AXLE GEAR 16X1,0
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 1mm.
45
Shim Mercedes-Benz
Mercedes-Benz Propeller shaft to front axle differential 0,5 MM
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 0,5mm. TO FRONT AXLE GEAR 16X0,5
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 0,5mm.
45
Shim Mercedes-Benz
Mercedes-Benz Propeller shaft to front axle differential 1,5 MM
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 1,5mm. TO FRONT AXLE GEAR 16X1,5
Inside diameter: 10mm
Outside diameter: 16mm
Material thickness: 1,5mm.
65
Hexagon Head Bolt Mercedes-Benz
$7.50
Mercedes-Benz M12X1.5X55
Diameter: 12mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1,5mm. Propeller shaft to rear axle m12x1,5x55.
70
Window Mercedes-Benz
$2.20
Mercedes-Benz Flexible joint disc to front propeller shaft. 12 mm. Propeller shaft to rear axle. 12 mm. Propeller shaft to transmission. 12 mm.
90
Bolt And Washer Assembly Mercedes-Benz
$3.50
Mercedes-Benz Reinforcement to side member. M10X25
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Reinforcement to body longitudinal member. Strut to reinforcement. Intermediate bearing to frame floor unit. Reinforcement to longitudinal member, left.
90
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz M10x25. Shock absorber to rear axle. Stiffening support to body side member. Reinforcement angle to side member. Intermediate bearing to frame floor unit. Hydropneumatic spring leg to rear axle. Protective plate to protective plate.
90
Hexagon Head Bolt Mercedes-Benz
$9.75
Mercedes-Benz INTERMEDIATE BEARING TO FIXTUREDiameter: 10mmStrength / hardness class: 10.9Thread code letter: MThread pitch: 1mm. ATTACHMENT, PIVOT BEARING EXT TO BACKREST FRAME, LHDiameter: 10mmStrength / hardness class: 10.9Thread code letter: MThread pitch: 1mm. HING ...
110
Washer Mercedes-Benz
$4.00
Mercedes-Benz FRONT BUMPER TO CROSS MEMBERDiameter: 10,5mmStrength / hardness class: 140 HVInside diameter: 10,5mmOutside diameter: 30mmMaterial thickness: 2,5mm. REAR BUMPER TO REAR BODY PANEL CROSS MEMBERDiameter: 10,5mmStrength / hardness class: 140 HVInside diameter ...
110
Control Arm Washer Mercedes-Benz
$4.20
Mercedes-Benz Washer
REAR BACKREST MOUNTINGDiameter: 10mmStrength / hardness class: 200 HVInside diameter: 10,5mmOutside diameter: 30mmMaterial thickness: 2,5mm. INTERMEDIATE BEARING TO FRAME FLOOR UNITDiameter: 10mmStrength / hardness class: 200 HVInside diameter: 10,5mmOutsi ...
120
Pk, Mounting Plate Mercedes-Benz
$129.00
Mercedes-Benz Propeller shaft to front axle gear. Propeller shaft to transfer case and to front axle. To transfer case m10.
