Foot Operated Parking Brake for 2008 Mercedes-Benz CLS550
No.
Part # / Description / Price
25
Cover
Mercedes-Benz
$11.50
Mercedes-Benz Pedal to 163 420 02 84/03 84. On foot-operated parking brake. Pedal to 208 420 00 84.
70
Hose Mercedes-Benz
Mercedes-Benz Front brake cable to parking brake. Brake cable to brake lever. For ground cable, fuel pump order by the meter. 12 mm. Front brake cable 15mm. On wire spiral, choke cable order by the meter.
80
Brake Cable Mercedes-Benz
Mercedes-Benz Release for foot operated parking brake 1435mm. Release for foot operated parking brake 1495mm.
110
Nut Mercedes-Benz
Mercedes-Benz Spring strut to body. M8
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
130
Cable Bracket Mercedes-Benz
$3.40
Mercedes-Benz Brake control cable to tunnel. Brake cable to frame. Front brake cable to fire wall. Brake cable guide. Front brake cable to tunnel. Brake cable 11 mm.
160
End Stop Mercedes-Benz
Mercedes-Benz Release for foot operated parking brake. To guide. Armrest. Release handle. Unlocking foot operated parking brake. Left and right.
Not For Sale
170
Securing Mercedes-Benz
$1.50
Mercedes-Benz Covering to instrument panel;electrically adjustable steering column. Guide to instrument panel.
180
Tapping Screw Mercedes-Benz
$1.50
Mercedes-Benz Instrument panel upper part to steering column jacket tube mounting plate 4.8 x 22. 4.8x16. Covering below instrument panel,left. 4.8x16. 4,8x22. 4.8x16. Instrument panel,bottom,driver's side. 4.8x16. Foot operated parking brake release handle to instrument panel 4.8 x 22. 4.8x16.
220
