Steering Knuckle and Wheel Hub for 2011 Mercedes-Benz R 350
No.
Part # / Description / Price
15
Hexagon Head Bolt
Mercedes-Benz
$3.40
Mercedes-Benz LEFT STEERING KNUCKLE
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. PROTECTIVE PLATE TO STEERING KNUCKLE
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
40
Retaining Ring Mercedes-Benz
$8.75
Mercedes-Benz Wheel bearing to left steering knuckle. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm. WHEEL BEARING TO WHEEL CARRIER LEFT. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm.
45
Repair Kit, Support Joint Mercedes-Benz
$127.00
Mercedes-Benz Repair Kit, Suppor. Joint
Steering knuckle. Carrier link.
47
50
Hex Nut W Flange + Piece Mercedes-Benz
$19.50
Mercedes-Benz Hex. Nut W Flange + Piece
Drive shaft to front wheel hub. M24x1.5. Rear axle shaft.
110
110
130
150
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz LEFT CONTROL ARM. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,REAR. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSVERSE CONTROL ARM AT BOTTOM TO INTEGRAL CARRIER. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
150
Hexagon Head Bolt Mercedes-Benz
$12.50
Mercedes-Benz M14X1,5X100-10.9
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. On frame-type int. Transverse control arm at bottom to integral carrier. Suspension strut to transverse control arm. Transverse control arm, rear, to frame-type integral support. Cross strut to integral carrier. Camber struts to wheel carrier. Trailing arm to rear axle, lower left and right.
150
Setting Screw, Control Arm Mercedes-Benz
$14.00
Mercedes-Benz Setting Screw, Ctrl. Arm
M14x1,5x105. Camber adjustment, bottom, front threaded connection point m14x1,5x100 mm.
155
Window Mercedes-Benz
$12.50
Mercedes-Benz Camber adjustment. Lower control arm. Rear axle carrier to rear frame floor assembly.
160
Nut Mercedes-Benz
$7.00
Mercedes-Benz Hydropneumatic spring leg to spring control arm. M14X1.5-10
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 29,9mm
Width across flats: 21mm. Control arm to support. To left transverse control arm. Control arm to frame,front. Lower control arm. Suspension strut to supporting joint.
180
Hexagon Head Bolt Mercedes-Benz
$45.00
Mercedes-Benz Left control arm. M14X1,5X37
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Lower control arm.
180
Hexagon Head Bolt Mercedes-Benz
$5.25
Mercedes-Benz LOWER CONTROL ARM. 14X37
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
200
Setting Screw, Control Arm Mercedes-Benz
$27.00
Mercedes-Benz Setting Screw, Ctrl. Arm
Camber adjustment, bottom, rear threaded connection point m14x37mm.
210
Hexagon Nut With Flange Mercedes-Benz
$8.00
Mercedes-Benz Left control arm. M14x1,5. Bottom outside. Lower control arm.
230
Bolt And Washer Assembly Mercedes-Benz
$9.50
Mercedes-Benz UPPER CONTROL ARM TO BODY
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm.
240
Hex Nut W Clamping Part Mercedes-Benz
$6.50
Mercedes-Benz Hex. Nut W Clamping Part
Upper transverse control arm to steering knuckle. M14x1.5.
250
Nut Mercedes-Benz
$4.50
Mercedes-Benz Suspension strut to spring linkDiameter: 16mmStrength / hardness class: 10Thread code letter: MThread pitch: 1,5mmOutside diameter: 34,5mmWidth across flats: 24mm. SHOCK ABSORBER TO LOWER CONTROL ARMDiameter: 16mmStrength / hardness class: 10Thread code le ...
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
