Rear Axle Mount for 2011 Mercedes-Benz R 350
No.
Part # / Description / Price
110
Repair Kit, Support Joint
Mercedes-Benz
$404.00
Mercedes-Benz Repair Kit, Suppor. Joint
Repair kit. Supporting joint lh.
115
Nut Mercedes-Benz
$4.50
Mercedes-Benz Suspension strut to spring linkDiameter: 16mmStrength / hardness class: 10Thread code letter: MThread pitch: 1,5mmOutside diameter: 34,5mmWidth across flats: 24mm. SHOCK ABSORBER TO LOWER CONTROL ARMDiameter: 16mmStrength / hardness class: 10Thread code le ...
140
Retaining Ring Mercedes-Benz
$8.75
Mercedes-Benz Wheel bearing to left steering knuckle. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm. WHEEL BEARING TO WHEEL CARRIER LEFT. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm.
200
Hex Nut W Flange + Piece Mercedes-Benz
$19.50
Mercedes-Benz Hex. Nut W Flange + Piece
Drive shaft to front wheel hub. M24x1.5. Rear axle shaft.
320
Bearing Element, Elastom Mercedes-Benz
Mercedes-Benz Rubber Bushing
Left control arm. Rear shock absorbers. Transverse control arm.
360
Protective Cap Mercedes-Benz
$3.70
Mercedes-Benz Bottom left transverse control arm at frame-type integral support. Left lower transverse control arm to integral carrier.
560
Nut Mercedes-Benz
$3.40
Mercedes-Benz Upper transverse control arm to bodyDiameter: 10mmStrength / hardness class: 10Thread code letter: MThread pitch: 1,5mmOutside diameter: 21,8mmWidth across flats: 16mm. Torsion bar linkage to torsion barDiameter: 10mmStrength / hardness class: 10Thread cod ...
570
Hexagon Head Bolt Mercedes-Benz
$3.50
Mercedes-Benz
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 16mm.
600
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz On frame-type int. M14X95
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Hydropneumatic spring leg to spring control arm. Right control arm. Shock absorber to spring link. Control arm to frame,front. Lower transverse control arm to left wheel carrier. Shock absorber to left and right rear axle. Shock absorber mount, lower left. Trailing arm to rear axle, upper left and right.
600
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz RIGHT CONTROL ARM
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,FRONT
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
610
Nut Mercedes-Benz
$7.00
Mercedes-Benz Hydropneumatic spring leg to spring control arm. M14X1.5-10
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 29,9mm
Width across flats: 21mm. Control arm to support. To left transverse control arm. Control arm to frame,front. Lower control arm. Suspension strut to supporting joint.
620
Hexagon Head Bolt Mercedes-Benz
$12.50
Mercedes-Benz M14X1,5X100-10.9
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. On frame-type int. Transverse control arm at bottom to integral carrier. Suspension strut to transverse control arm. Transverse control arm, rear, to frame-type integral support. Cross strut to integral carrier. Camber struts to wheel carrier. Trailing arm to rear axle, lower left and right.
620
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz LEFT CONTROL ARM. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,REAR. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSVERSE CONTROL ARM AT BOTTOM TO INTEGRAL CARRIER. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
640
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz STRUT TO REAR SUBFRAME
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
640
Hexagon Head Bolt Mercedes-Benz
$6.00
Mercedes-Benz Torque strut to frame-type integral support, left and right. M12X1,5X60
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to rear subframe. Torsion bar to rear axle carrier. Inner. Left tie rod to wheel carrier. Suspension strut at bearing bracket.
650
Nut Mercedes-Benz
$7.75
Mercedes-Benz M12X1.5-10
Diameter: 12mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 26mm
Width across flats: 18mm. Strut to rear subframe. Torsion bar to rear axle. Rod to shock absorber strut.
660
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Strut rod to wheel carrier, left and right. M12X1,5X85
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to wheel bearing. Brake caliper to left wheel carrier. Left tie rod to wheel carrier. Spring link to left wheel carrier.
660
Hexagon Head Bolt Mercedes-Benz
$17.50
Mercedes-Benz STRUT TO WHEEL BEARING
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
670
Window Mercedes-Benz
$8.00
Mercedes-Benz Strut rod to left wheel carrier. Camber struts to wheel bearing. Strut rod to wheel carrier, lh.
700
Eccentric Screw Mercedes-Benz
$15.50
Mercedes-Benz Camber strut to left rear axle carrier. Camber struts to rear subframe.
710
Window Mercedes-Benz
$0.30
Mercedes-Benz Tie rod to rear axle carrierDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. CAMBER STRUTS TO REAR SUBFRAMEDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. TIE ROD TO REAR SUBFRAMEDi ...
730
Hexagon Head Bolt Mercedes-Benz
$14.00
Mercedes-Benz Upper left transverse control arm to body. M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing on rear axle carrier, front. Camber struts to wheel carrier. Transmission to subframe m12x1,5x95. Axle housing to rear subframe. Axle housing to rear axle carrier, rear. Torsion bar to rear axle carrier. Vibration absorber.
730
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz CAMBER STRUTS TO WHEEL CARRIER
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSMISSION TO SUBFRAME M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
800
Eccentric Screw Mercedes-Benz
$12.00
Mercedes-Benz Tie rod to rear-axle bracket, left and right. M12x1,5,78. Tie rod to rear subframe left. Tie rod to left rear axle carrier.
