Frame Floor Unit Main Cable Harness for 2003 Mercedes-Benz E500
No.
Part # / Description / Price
30
Coupling, Mechanical
Mercedes-Benz
$5.75
Mercedes-Benz Front axle distributor in maj. Ass. Comp. Brake wear indicator x62/7. 2 pin mqs
model 1: mqs
slots: 2. Pressure converter exhaust gas recirculation. 2 pin mqs
model 1: mqs
slots: 2. Brake lining wear indicator plugconnection,rear x88/15. 2 pin mqs
model 1: mqs
slots: 2. Coolant level s41. 2 pin mqs
model 1: mqs
slots: 2.
35
Pin Housing Mercedes-Benz
$9.50
Mercedes-Benz Nox sensor separation point x86/1. 4-pin lks. 02 sensor after catalytic converter 4-pin. 4-pin lks. Connector housing, nox sensor connecting point x86/1. 4-pin lks. Differential pressure sensor x25/12. 4-pin lks. Four pin, for oxygen sensor downstream of catalytic converter. 4-pin lks.
35
Contact Carrier Mercedes-Benz
$7.50
Mercedes-Benz Contact Support
Nox sensor separation point x86/1. 4-pin lks1.5. 4-pole to 210 540 62 81. 4-pin lks1.5.
40
Plug Mercedes-Benz
$5.50
Mercedes-Benz Left front door connector, green x35/1. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Emergency speaker connector right front x18/36. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pin slk2 ...
70
Plug Mercedes-Benz
Mercedes-Benz Contact strip driver side yellow x55/3. 12-pin. Intermediate connector, airbag. 12-pin. Cockpit cable harness plug-connection. 12-pin.
80
100
Contact Support Mercedes-Benz
$4.70
Mercedes-Benz Connector, rear axle distributor, black x62/8. 4-pin mqs. Rear axle transfer case plugconnection x62/33. 4-pin mqs. Connector, left rear axle electrical distributor, black x62/32*1. 4-pin mqs. Rear axle distributor x62/33. 4-pin mqs. Rear axle separation point x62/8 code a. 4-pin mqs.
100
Contact Carrier Mercedes-Benz
$4.70
Mercedes-Benz Contact Support
Connector, left rear axle electrical distributor, violet x62/32*4. 4-pin mqs. Connector, rear axle distributor, violet x62/32,x62/33,cod.d. 4-pin mqs. Rear axle separation point x62/8 code d. 4-pin mqs.
100
Contact Support Mercedes-Benz
Mercedes-Benz Rear axle transfer case plugconnection x62/8. 4-pin mqs. Distributor rear axle left, neutral x62/32. 4-pin mqs. Rear axle distributor x62/33. 4-pin mqs.
110
Receptacle Housing Mercedes-Benz
$6.00
Mercedes-Benz Exhaust gas aftertreatment k27/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Restraint system k40/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. K74. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Relay, stop lamp suppression 9 ...
120
Plug Mercedes-Benz
$20.00
Mercedes-Benz Connector diagnostics x11/4. 16-pin mt3model 1: mtmodel 2: 3slots: 16release tool: w220 589 01 99 54. DIAGNOSIS PLUG. 16-PIN MT3Model 1: MTModel 2: 3Slots: 16Release tool: W220 589 01 99 54. Separation point, cockpit cable harness x35/66. 16-pin mt3model 1 ...
125
Contact Spring Mercedes-Benz
$6.00
Mercedes-Benz Data link connector x11/4. 0.5-1.0 mm2 mt3. Separation point, cockpit cable harness x35/66. 0.5-1.0 mm2 mt3. Data link connector x 11/4. 0.5-1.0 mm2 mt3. Connector diagnostics x11/22. 0.5-1.0 mm2 mt3.
130
Fuse Box Mercedes-Benz
$5.75
Mercedes-Benz Interior fuse box slot 24 f34. Lower control panel rear f1/7. Sam/srb rear n10/2. Line connection n 10/2. Russet brown f1/6. Plug position: 70 f4. Rear prefuse box, brown f33. Russet brown f34, code b.
130
Fuse Box Mercedes-Benz
$7.25
Mercedes-Benz Cool box n10/2. Interior fuse box f1/7. Fuse box interior plug position 25 f34. Fuse box interior plug position 26 f34. Control module sam/srb rear n 10/2. Signal acquisition and actuation module, rear n10/2. Prefuse box at rear light blue f33. Turquoise f34, code c.
130
Fuse Box Mercedes-Benz
$3.90
Mercedes-Benz Control module sam/srb front, green n10/1. Instrument panel left f1/7. Sam/srb rear n10/2. Fuse box interior plug position 39 f34. Interior fuse box slot 23 f34. Code black color. Control module sam/srb rear n 10/2. Black f34, code a.
200
Plug Mercedes-Benz
$10.50
Mercedes-Benz Diagnostic socket (lamp unit) e1. 5-pin slk2.8. Delivery unit with fill level sensor a92. 5-pin slk2.8. Fuel pump m3/3. 5-pin slk2.8. Plug connection for fuel pump wiring harness x36/3,code a. 5-pin slk2.8.
230
Plug Mercedes-Benz
$8.00
Mercedes-Benz On-board elec. Partition point microphone sound syst. Bus node connector (can) left (coding a) x30/5. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60. Central gateway control module. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60 ...
240
Distributor Mercedes-Benz
$37.00
Mercedes-Benz Can bus distributor x30/5. 12x2/1x3 pin. Potential distributor can c x63/4. 12x2/1x3 pin. Can bus c, right x30/19. 12x2/1x3 pin. Can c connector x63/4. 12x2/1x3 pin. Connector can databus x63/4,. 12x2/1x3 pin. Can bus c, left x30/5. 12x2/1x3 pin. Can bus c x30/18. 12x2/1x3 pin. Can bus c, left x63/4. 12x2/1x3 pin. Voltage distributor, can bus 27-pin. 12x2/1x3 pin.
250
Line Connector Mercedes-Benz
$7.00
Mercedes-Benz Connector distributor wake-up/ diagnostics 10-pin x30/14. 10-pin slk2.8. Distributor, terminal 58d x30/13. 10-pin slk2.8. Connector distributor wake-up/ diagnostics 10-pin x 30/14. 10-pin slk2.8. Potential distributor kl.31 z204/5. 10-pin slk2.8. Plug distributor wake-up signal 10 pin x30/8,. 10-pin slk2.8. Below left rear seat z204/6. 10-pin slk2.8. Distributor, terminal 15 x30/9,code a. 10-pin slk2.8.
260
Plug Mercedes-Benz
Mercedes-Benz Automatic rear-end door S62/37. 2 PIN. Diagnosis distronic connector x11/36,code e. 2 pin.
265
Plug Mercedes-Benz
Mercedes-Benz Connector easy-shift manual transm. Automatic transmission plug-connection x22/17. 18 pin.
270
Plug Mercedes-Benz
$8.50
Mercedes-Benz Connector cockpit/frame floor system x18*2. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Separation point trunk lid 6-pin x8/4. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Connector for engin ...
275
Coupling Housing, Elec Mercedes-Benz
$17.50
Mercedes-Benz Wiper motor m6/1. 4-pin slk2.8. Left lighting unit e1. 4-pin slk2.8. Diagnostic socket (lamp unit) e1. 4-pin slk2.8. Plug connection for fuel pump wiring harness x36/3. 4-pin slk2.8. Engine cable harness plug-connection x26. 4-pin slk2.8. Lighting unit e1 e2 (s1). 4-pin slk2.8. Connector X26/2 Engine connecting point. 4-PIN SLK2.8. Plug connection engine/body x26/2. 4-pin slk2.8. Headlamp range adjustment left. 4-pin slk2.8. Lamp unit left and right e1/e2. 4-pin slk2.8.
280
Plug Mercedes-Benz
$7.50
Mercedes-Benz Separation point, residual engine heat/differential pressure sensor x25/11. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8. Plug connection for engine,cockpit. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8. Connector, interior/engine black x18/7. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8.
300
Plug Mercedes-Benz
Mercedes-Benz Plug connection for fuel pump wiring harness x36/3,code a. 4 pin
model 1: jpt
model 2: 2.8
slots: 4. Left lighting unit. 4 pin
model 1: jpt
model 2: 2.8
slots: 4.
304
Plug Housing Mercedes-Benz
$6.25
Mercedes-Benz Can connector d x30/39. 3-pin mqs. Connector, drive train can potential distributor x30/21. 3-pin mqs. Powertrain can bus node connector x30/21. 3-pin mqs.
306
Plug Mercedes-Benz
Mercedes-Benz To electric motor. 8-pin slk2.8. Connector, electronic steering column adjustment x19/2. 8-pin slk2.8. Rpm-sensor signal connector x62. 8-pin slk2.8. Rpm sensor connector, transparent x62. 8-pin slk2.8.
310
Electrical Line Mercedes-Benz
$9.75
Mercedes-Benz WITH GASKET. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. With single-wire seal. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
325
Electrical Wiring Harness Mercedes-Benz
$7.75
Mercedes-Benz WITH CATCH SPRING,WITH SINGLE-WIRE SEAL. 1.0 MM2 LKS1.5
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: Ag
Model 1: LKS
Model 2: 1.5.
327
Crimp Pin Contact, Rect Mercedes-Benz
$5.50
Mercedes-Benz Tin-plated. 0.5 MM2 MLK1.2
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 83. With single-wire seal. 0.5 MM2 MLK1.2
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 83.
330
Electric Line Mercedes-Benz
$9.00
Mercedes-Benz WITHOUT SEAL. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
330
Contact Spring Mercedes-Benz
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
340
Contact Spring Mercedes-Benz
$3.90
Mercedes-Benz Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
350
Contact Spring Mercedes-Benz
$5.00
Mercedes-Benz 0.35 MM2. 0.22-0.35 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
360
Plug Mercedes-Benz
$4.00
Mercedes-Benz Male Spade Connector
Tin-plated. 0.5-0.75 MM2 SLK2.8. Front door connector to frame floor system. 0.5-0.75 mm2 slk2.8. Circuit 15r/58d connector x39/29. 0.5-0.75 mm2 slk2.8. Module box separation point x35/15. 0.5-0.75 mm2 slk2.8. Radio remote control separation point for central locking x35/71. 0.5-0.75 mm2 slk2.8. Silver. 0.5-0.75 mm2 slk2.8. 0,5-1,0mm. 0.5-0.75 mm2 slk2.8. To a 220 545 92 28. 0.5-0.75 mm2 slk2.8.
365
Electric Line Mercedes-Benz
$7.50
Mercedes-Benz With seal. 1.0 MM2 LKS 1.5
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: LKS
Model 2: 1.5. Fuel delivery pump control unit n118. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5. Oxygen sensor downstream of catalytic converter g3/5. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5.
365
Electrical Wiring Harness Mercedes-Benz
$9.50
Mercedes-Benz Fuel delivery pump control unit n118. 2.5 mm2 lks
leitungsquerschnitt min/max: 2,5mm2
model 1: lks.
370
Electric Line Mercedes-Benz
$7.75
Mercedes-Benz Repair solution contacting 0,75 mm2. MQS. 0.75 MM2 MQS
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
375
Contact Socket Mercedes-Benz
$3.70
Mercedes-Benz Differential pressure sensor B28/8. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: +Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 09. SHUTOFF VALVE ACTIVATED-CARBON FILTER Y58. 1 ...
375
Contact Socket Mercedes-Benz
$3.70
Mercedes-Benz DOOR LOCK. 0.5-0.75 MM2 SLK2.8Leitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: AgELA: +Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 09. Airbag trigger unit, in front module left and right b48/1. Lighting ...
380
Electric Line Mercedes-Benz
$14.50
Mercedes-Benz WITH GASKET. 1.5-2.5 MM2 JPTLeitungsquerschnitt Min/Max: 1,5-2,5mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 1.5-2.5 MM2 JPTLeitungsquerschnitt Min/Max: 1,5-2,5mm2Model 1: JP ...
385
Spring Retaining Pin Mercedes-Benz
$3.90
Mercedes-Benz Contact Spring
1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
385
Contact Spring Mercedes-Benz
$4.90
Mercedes-Benz Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
396
Plug Mercedes-Benz
$4.40
Mercedes-Benz Module box separation point x35/15. 3-pin. Radio remote control separation point for central locking x35/71. 3-pin. Separation point trunk lid 14-pin x8/4. 3-pin. Control unit box/engine sep. Point x35/63. 3-pin.
400
Housing Mercedes-Benz
$11.50
Mercedes-Benz Rear axle transfer case plugconnection x62/32. Rear axle distributor. 4x4-pin. Rear axle transfer case plugconnection x62/8. 4x4-pin. Rear axle,left and right x62/32, x62/33. 4x4-pin. Rear axle separation point x62/8. 4x4-pin.
410
Relay Mercedes-Benz
Mercedes-Benz Changer. Plug position: g/h. Plug position: p. Cooling water pump k60. Tank cap pole reversal 1, slot:. Luggage compartment,right. Slot p. Remote trunk release. K41/1. Filler cap, inner.
460
520
630
Housing Mercedes-Benz
Mercedes-Benz Prefuse box front, black f32. 1-pin
model 1: lsk
model 2: 8
slots: 1. Rear prefuse box, neutral f33. 1-pin
model 1: lsk
model 2: 8
slots: 1. Rear prefuse box, blue f33. 1-pin
model 1: lsk
model 2: 8
slots: 1.
640
Contact Socket Mercedes-Benz
$4.00
Mercedes-Benz Fuse and relay module, front passenger k40/4. I1. 6.0-10.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. With single-wire seal. 6.0-10.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
640
Electrical Wiring Harness Mercedes-Benz
$12.00
Mercedes-Benz Silver-plated. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgModel 1: LSKModel 2: 8Release tool: W220 589 01 99 56. Central electrics in eng. COMPARTMENT LEFT FRONT N10/1. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Obe ...
800
Plug Mercedes-Benz
Mercedes-Benz Intermediate connector, airbag x28/12. 12-pin. Connector block, left seat x55/5. 12-pin.
810
Plug Mercedes-Benz
$4.20
Mercedes-Benz Cockpit/electric steering lock connector x190. 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. Left rear door connector to frame floor system (x35/3). 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. ...
820
Plug Mercedes-Benz
$2.70
Mercedes-Benz Transmission diagnosis connection x11/32. 2-pin mqs. Radio "mute" plug connection x39/12. 2-pin mqs. Two-way radio speaker separation point x1/45. 2-pin mqs. Connector rear floor frame floor system x8/18. 2-pin mqs. Separation point microphone hands-free system x58/3. 2-pin mqs. M2/2. 2-pin mqs. Separation point aux. Turn sign. Ind. X52/5. 2-pin mqs.
870
Electric Line Mercedes-Benz
$9.50
Mercedes-Benz Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
