Rear End Floor for 2003 Mercedes-Benz E500
No.
Part # / Description / Price
60
Cover Plate
Mercedes-Benz
Mercedes-Benz To cross member above rear axle. Rear side member. At cross member, rear axle.
260
Bolt And Washer Assembly Mercedes-Benz
$3.50
Mercedes-Benz Reinforcement to side member. M10X25
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Reinforcement to body longitudinal member. Strut to reinforcement. Intermediate bearing to frame floor unit. Reinforcement to longitudinal member, left.
290
Hexagon Head Screw Mercedes-Benz
$0.70
Mercedes-Benz M5x10.5. At blower;temperature sensor ventilation. Bracket to fire wall. Heat shield mounting. Control unit. Screening plates. Main floor,front right. Return line to partition panel.
310
Grommet Mercedes-Benz
$5.50
Mercedes-Benz On left front rocker panel. 26 mm. Floor water drain,lateral left & right. 26 mm. Water drain left longitudinal member. 26 mm. Side panel water drain 26 mm. 26 mm. Left and right rear side members. 26 mm. On door sill, left. 26 mm. Spare wheel well water drain. 26 mm. In rear locking lug below left and right. 26 mm.
800
Threaded Pin Mercedes-Benz
$35.00
Mercedes-Benz Repair solution for broken weld stud. (parts kit),line mounting. (parts kit) on left and right wheelhouses. Fuel and brake lines to main floor, left. Wheelhouse covering. Repair solution for ruptured welded pins menge nach bedarf.
