Refrigerant Line Arrangement for 2003 Mercedes-Benz E500
No.
Part # / Description / Price
20
Sealing Ring
Mercedes-Benz
Mercedes-Benz Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
30
Valve Element Mercedes-Benz
$19.50
Mercedes-Benz Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
70
Sealing Ring Mercedes-Benz
$3.60
Mercedes-Benz Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
72
72
Cap Screw Mercedes-Benz
$6.00
Mercedes-Benz M8X30-10.9
Diameter: 8mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Steering coupling to steering shaft. Line to compressor. Stop buffer to frame. Plug connection, separation point.
105
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Sealing Ring
AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
110
O-Ring Mercedes-Benz
$3.20
Mercedes-Benz Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
115
Rear AC Line Guide Mercedes-Benz
$6.25
Mercedes-Benz Guide
Pipe line to condenser. Refrigerant line. At condenser. From condenser to liquid tank. Pressure line to condenser. Roof Mounted A/C. All Required. Center. Pipeline.
155
Sealing Ring Mercedes-Benz
$3.70
Mercedes-Benz Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
155
O-Ring Mercedes-Benz
$4.00
Mercedes-Benz Pressure line to expansion valve. 7.5x2.1. Tubing at expansion valve. 7.5x2.1. Refrigerant line. 7.5x2.1.
310
Clamping Piece Mercedes-Benz
$2.70
Mercedes-Benz Line mounting. 5 mm. Line aux.heater left rear seat floor. 5 mm. Damper strut delivery line. 5 mm. Pressure line to shock-absorber strut. 5 mm. Front brake cable to tunnel. 5 mm. Pipe line to wheelhouse. 5 mm. Rear floor assembly right. 5 mm. To right rear wheelhouse. 5 mm.
320
350
Temperature Sensor Mercedes-Benz
$80.00
Mercedes-Benz To condenser. On liquid reservoir. Refrigerant pressure and temperature sensor. Coolant temperatuter sensor.
350
Pressure Sensor Mercedes-Benz
$159.00
Mercedes-Benz Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
501
Receptacle Housing Mercedes-Benz
$5.75
Mercedes-Benz 4-PIN MQS
Model 1: MQS
Slots: 4
Release tool: W220 589 01 99 60.
