Fuel Lines for 1992 Mercedes-Benz 400SE
No.
Part # / Description / Price
6
Hose
Mercedes-Benz
$32.50
Mercedes-Benz 160 mm. 13.3x3 mm. From fuel filter to feed line. 13.3x3 mm. 300 mm. 13.3x3 mm. 110mm. 13.3x3 mm. Order by the meter. 13.3x3 mm. 250 mm. 13.3x3 mm. From activated charcoal filter to regeneration valve. 13.3x3 mm. 100 mm from fuel return line to fuel tark. 13.3x3 mm.
68
Hose Mercedes-Benz
Mercedes-Benz From return line to fuel tank. From filter to engine. Distributor to regeneration valve, right.
71
Spring Hose Clamp Mercedes-Benz
$4.00
Mercedes-Benz Between combination valve and breather pipe. Regeneration valve. Return hose to return line. From fuel tank to breather valve.
86
Tensioner Mercedes-Benz
$5.00
Mercedes-Benz Underbody left. Fuel line to floor,right. To mount fuel lines. In wheelhouse front left. To firewall and longitudinal member. Brake line to cross member.
104
Holder Mercedes-Benz
$6.50
Mercedes-Benz Activated charcoal filter. Windshield washer pipe line to right side member. Aeration/ventilation. Regeneration line. Line to cross member. Fuel line to partition panel. On damper strut dome bracket,right. Pipe line to right wheel arch.
119
Clamp Mercedes-Benz
$2.90
Mercedes-Benz Fuel lines on floor under rear seat. Feed line to air water canal. Fuel lines to vehicle floor 17 x 20 mm. Fuel lines to body. Return line to body. Cable harness mounting. High pressure hose to cross member.
131
Damping Strip Mercedes-Benz
Mercedes-Benz Fastening fuel lines to longitudinal member. Fuel lines to vehicle floor. Extinguishing agent line. Fuel lines on floor under rear seat. Feed line. Fuel line mounting. Gas line. Return line to body. Cable harness mounting. High pressure hose to cross member.
143
Rubber Guide Mercedes-Benz
$7.25
Mercedes-Benz Fuel lines to body. Lines to rear floor above rear axle, center. Fuel lines to cowl. Lines to frame. Fuel lines to front partition panel. Fuel lines under rear seat. Mounting pipe line.
