Refrigerant Line Arrangement for 1992 Mercedes-Benz 400SE
No.
Part # / Description / Price
10
Rubber Bushing
Mercedes-Benz
Mercedes-Benz At right side member. Heater unit. At left side member. Bracket to wheel arch panel. Bracket to right wheelhouse. Pipe line to side member.
20
Valve Element Mercedes-Benz
$10.50
Mercedes-Benz To 129 830 01 70. To 140 830 20 15. Compressor-to-condenser refrigerant line.
32
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Hexagon Head Bolt
Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
38
Sealing Ring Mercedes-Benz
$3.70
Mercedes-Benz Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
53
Sealing Ring Mercedes-Benz
Mercedes-Benz Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
58
Clamp Mercedes-Benz
$9.00
Mercedes-Benz HIGH PRESSURE HOSE TO FRAME. 25/15Inside diameter: 25mmMaterial thickness: 0,8mmModel 1: W1. 24mm. 25/15Inside diameter: 25mmMaterial thickness: 0,8mmModel 1: W1. LEFT REAR. 25/15Inside diameter: 25mmMaterial thickness: 0,8mmModel 1: W1. Muffler. 25/15Insi ...
66
67
Sealing Ring Mercedes-Benz
Mercedes-Benz Pressure switch to liquid tank used for additional blower. 9.0 x 1.8 mm. Pressure switch to liquid tank used for compressor. 9.0 x 1.8 mm. At liquid tank. 9.0 x 1.8 mm. Refrigerant reservoir valve. 9.0 X 1.8 MM. Sensor. 9.0 x 1.8 mm.
71
Hexagon Head Screw Mercedes-Benz
$0.70
Mercedes-Benz M5x10.5. At blower;temperature sensor ventilation. Bracket to fire wall. Heat shield mounting. Control unit. Screening plates. Main floor,front right. Return line to partition panel.
80
Discharge Line Valve Mercedes-Benz
$22.50
Mercedes-Benz Valve
Condenser. To 140 830 05 70. To 129 830 02 70,129 830 04 70. Filling valve. In pressure line.
89
95
Screw Mercedes-Benz
$7.50
Mercedes-Benz SWITCH ON BLOWER CASEDiameter: 6mmStrength / hardness class: 8.8Thread code letter: MThread pitch: 1mm. CONDENSER TO RADIATORDiameter: 6mmStrength / hardness class: 8.8Thread code letter: MThread pitch: 1mm. IGNITION COIL TO BRACKETDiameter: 6mmStrength / ...
98
Seal Mercedes-Benz
Mercedes-Benz Between condenser and radiator,top 112 mm. Between condenser and radiator,top 350 mm.
102
110
Bolt And Washer Assembly Mercedes-Benz
Mercedes-Benz To 140 470 01 47. Bracket to auxiliary blower m 5x12. Bracket to whelhouse flange. Additional blower to condenser.
No.
Part # / Description / Price
32
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Screw
Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
