Cable Harness for Air Conditioner and Headlamp Cleaning System for 2006 Mercedes-Benz C230
No.
Part # / Description / Price
10
20
20
24
Electric Line
Mercedes-Benz
$7.75
Mercedes-Benz AIR CONDITIONING MULTIFUNCTION SENSOR B31/1. 0.5 MM2 MQSLeitungsquerschnitt Min/Max: 0,5mm2Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Belt locking retractor plug-connection x28/8. X28/9. 0.5 MM2 MQSLeitungsquerschnitt Min/Max ...
26
Plug Mercedes-Benz
$6.00
Mercedes-Benz Connector sun sensor x28/26. 4-pin slk2.8model 1: mcpmodel 2: 2.8slots: 4release tool: w000 589 13 99 30. HYDRAULIC PUMP M51/1. 4-PIN SLK2.8Model 1: MCPModel 2: 2.8Slots: 4Release tool: W000 589 13 99 30. Connector, interior and subharness for taillamp x18 ...
28
Contact Spring Mercedes-Benz
$5.00
Mercedes-Benz 0.35 MM2. 0.22-0.35 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
30
Receptacle Housing Mercedes-Benz
$7.00
Mercedes-Benz Windshield/headlamp washer. 2-pin jpt. Washer fluid pump headlamps. 2-pin jpt. Windshield washer pump;2-pole. 2-pin jpt. Headlamp cleaning system pump in container. 2-pin jpt. Pump connection. 2-pin jpt.
40
Coupling, Mechanical Mercedes-Benz
$10.50
Mercedes-Benz Door control module left, black n69/1. 7-pin mqs/mcp2.8. Front left door control. 7-pin mqs/mcp2.8. Control module sam/srb front, black n10/1. 7-pin mqs/mcp2.8. Fuse and relay module, driver n10/1 / 15. 7-pin mqs/mcp2.8. Door control unit at driver door, left and right n69/1 n69/2. 7-pin mqs/mcp2.8.
60
Receptacle Housing Mercedes-Benz
$5.75
Mercedes-Benz 4-PIN MQS
Model 1: MQS
Slots: 4
Release tool: W220 589 01 99 60.
70
Electric Coupling Mercedes-Benz
$3.00
Mercedes-Benz Blinker lamp. 2-pin rk4. Circulation pump m13. 2-pin rk4. Circulation pump 2-pin. 2-pin rk4.
100
Electric Line Mercedes-Benz
$9.50
Mercedes-Benz Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
110
Electric Line Mercedes-Benz
$14.50
Mercedes-Benz WITH GASKET. 1.5-2.5 MM2 JPTLeitungsquerschnitt Min/Max: 1,5-2,5mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 1.5-2.5 MM2 JPTLeitungsquerschnitt Min/Max: 1,5-2,5mm2Model 1: JP ...
120
Electric Line Mercedes-Benz
$7.75
Mercedes-Benz Repair solution contacting 0,75 mm2. MQS. 0.75 MM2 MQS
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
140
Contact Socket Mercedes-Benz
$7.00
Mercedes-Benz BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
150
Core Bundle Sealing Mercedes-Benz
$2.40
Mercedes-Benz Left/right power window motor m40/5. M40/6. 1.0-2.5 MM JPT/MCP2.8/HDK2.8Leitungsquerschnitt Min/Max: 2,2-3,0mm2Model 1: MCPModel 2: 2.8. AS REQUIRED. 1.0-2.5 MM JPT/MCP2.8/HDK2.8Leitungsquerschnitt Min/Max: 2,2-3,0mm2Model 1: MCPModel 2: 2.8. PLUG HOUSING. ...
300
320
Socket-Outlet Mercedes-Benz
$6.25
Mercedes-Benz Connecting point, interior/front end x174/3. 4-pin mqs. X172/1. 4-pin mqs. Connector, front bumper frame floor assembly x 172/1. 4-pin mqs. Connector engine-body/ ac x85/7. 4-pin mqs. Exterior. 4-PIN MQS.
