Refrigerant Line Arrangement for 2006 Mercedes-Benz C230
No.
Part # / Description / Price
15
Sealing Ring
Mercedes-Benz
$3.70
Mercedes-Benz Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
16
Metal Mounting Sheet Mercedes-Benz
$8.00
Mercedes-Benz At dehydrator. Pressure lines to drier. Drier to condenser.
20
Pressure Sensor Mercedes-Benz
$159.00
Mercedes-Benz Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
30
32
Rear AC Line Guide Mercedes-Benz
$6.25
Mercedes-Benz Guide
Pipe line to condenser. Refrigerant line. At condenser. From condenser to liquid tank. Pressure line to condenser. Roof Mounted A/C. All Required. Center. Pipeline.
33
O-Ring Mercedes-Benz
$3.20
Mercedes-Benz Sealing Ring
Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
36
Valve Element Mercedes-Benz
$19.50
Mercedes-Benz Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
40
Grommet Mercedes-Benz
Mercedes-Benz Suction line to bracket. At solenoid valve. Mounting solenoid valve. Solenoid valve to crossmember. At bracket on shock absorber console.
55
70
Piping Mercedes-Benz
$165.00
Mercedes-Benz From expansion valve separation point. Expansion valve to separation point.
75
Sealing Ring Mercedes-Benz
Mercedes-Benz Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
80
Spacer Mercedes-Benz
Mercedes-Benz Rubber Guide
Fuel line to side member. For fuel line to longitudinal member. Fuel lines to front partition panel.
214
Sealing Ring Mercedes-Benz
$3.60
Mercedes-Benz Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
215
A/C Line O-Ring Mercedes-Benz
$14.50
Mercedes-Benz Sealing Ring
SUCTION LINE 13.7X2.5 MM. 13.7X2.5
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
260
280
Round-Sect Sealing Ring Mercedes-Benz
Mercedes-Benz Round-Sect. Sealing Ring
Piping to condenser. 10.6X2. Line to compressor. 10.6x2.
285
Screw Mercedes-Benz
$3.70
Mercedes-Benz Engine front mounting to front subframe. See spare parts list 004,group 22,fig.no.32 see spare parts list 005,group 22,fig.no.24 see spare parts list 006,group 22,fig.no.29 see spare parts list 004,group 22,fig.no.60 see spare parts list 005,group 22,fig.n ...
286
