Frame Floor Unit Main Cable Harness for 2006 Mercedes-Benz C230
No.
Part # / Description / Price
100
110
Plug
Mercedes-Benz
$3.00
Mercedes-Benz Pressure sensor, front door b48/7,b48/8. 3 pin. Tilting cone sensor. 3 pin. Control unit to side part b48/7, b48/8. 3 pin. Sensor side airbag left a53/1. 3 pin. Airbag pressure sensor b48/7,b48/8,b48/9,b48/10. 3 pin. Sensor sidebag a53, a54. 3 pin. Sensor side airbag right a54. 3 pin.
140
Plug Mercedes-Benz
$5.00
Mercedes-Benz Plug distributor radio mute x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio "mute" plug connection x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. ...
170
Cover Cap Mercedes-Benz
Mercedes-Benz Speed-sensitive power steering conn. Antenna module. 6-pin. Antenna amplifier to rear window to 001 545 51 40. 6-pin.
190
Receptacle Housing Mercedes-Benz
$3.40
Mercedes-Benz Left/right entrance/ex it lamp. 2 pin jpt. Luggage compartment lamp. 2 pin jpt. Glove compartment lamp. 2 pin jpt. Glove box lamp E13/1. 2 PIN JPT. Driver and front passenger footwell lamp e17/15, e17/16. 2 pin jpt. Left exit lights. 2 pin jpt. Courtesy lamp. 2 pin jpt. Interface. 2 pin jpt. Glove compartment lighting e13/2. 2 pin jpt. Vanity mirror illumination e14/6 e14/7. 2 pin jpt.
210
Receptacle Mercedes-Benz
Mercedes-Benz Door contact switch s17/1. S17/2. 3-pin. Door contact, b-pillar, left s17/3. 3-pin. Roof rack plug-in connection. 3-pin. Connector cockpit roof x18/23. 3-pin. Left front door connector x34/1. 3-pin. Left rear door contact switch S17/3,S17/4. 3-PIN. Door contact switch,left and right s17/3 / s17/4. 3-pin.
230
Housing Mercedes-Benz
$4.70
Mercedes-Benz Right rear belt tensioner r12/7. 2-pin mqs
model 1: mqs
slots: 2. Rear left door separation point x35/3. 2-pin mqs
model 1: mqs
slots: 2. Left rear seat belt tensioner squib connector X28/47. 2-PIN MQS
Model 1: MQS
Slots: 2. Front emergency tensioning retractor r46. 2-pin mqs
model 1: mqs
slots: 2.
240
Coupling, Mechanical Mercedes-Benz
$2.80
Mercedes-Benz Separation point, roof lock x113. 2 pin mqs. Connector block driver seat x55/3. 2 pin mqs. Multi-point plug driver side x55/3. 2 pin mqs. Yellow driver's side contact strip X55/3. 2 PIN MQS. Connector digital crash input 2-pin x28/24. 2 pin mqs. Contact strip, seat, left and right x55/3 x55/4. 2 pin mqs.
240
Housing Mercedes-Benz
$3.50
Mercedes-Benz Left front door connector x35/1. 2-pin mqs
model 1: mqs
slots: 2. Contact strip driver side yellow x55/3. 2-pin mqs
model 1: mqs
slots: 2. Left rear emergency tensioning retractor squib r12/6. 2-pin mqs
model 1: mqs
slots: 2. Belt lock switch s68/1 s68/2. 2-pin mqs
model 1: mqs
slots: 2.
242
Clutch Housing Mercedes-Benz
$6.25
Mercedes-Benz Alarm call pushbutton 4-pin s93/3. 4-pin mqs
model 1: mqs
slots: 4. Connector, weight sensing system x28/46. 4-pin mqs
model 1: mqs
slots: 4. Contact strip front pass. Side yel. X55/4. 4-PIN MQS
Model 1: MQS
Slots: 4.
250
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz "sam" control unit rear. 4-pin mcp 2.8. Control module sam/srb front, blue n10/1,. 4-pin mcp 2.8. Sam/srb control module, rear blue n10/2, code c. 4-pin mcp 2.8. Central locking system n10/2 13. 4-pin mcp 2.8. Fuse and relay module, driver n10/1/12. 4-pin mcp 2.8.
260
Plug Mercedes-Benz
$4.00
Mercedes-Benz Left rear door control module n69/8. 4-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 4release tool: w000 589 13 99 30. Taillamp left E3/1. 4-PIN MCP2.8Model 1: MCPModel 2: 2.8Slots: 4Release tool: W000 589 13 99 30. Control module keyless go black n69/9. 4-pin ...
270
Plug Mercedes-Benz
Mercedes-Benz Electronic ignition lock (ezs) control unit n73*2. 2-pin mcp2.8. Signal acquisition and actuation module with rear fuse and relay module. 2-pin mcp2.8. Front sam/srb control module, neutral n10/1,. 2-pin mcp2.8. Sam/srb control module rear neutral n10/2, code b. 2-pin mcp2.8. Fuse and relay module, driver n10/1 / 11. 2-pin mcp2.8.
300
Receptacle Mercedes-Benz
$4.50
Mercedes-Benz Coupling, Mechanical
Sam control unit. 3-pin. Fuse and relay module, driver n10/1 /1. 3-pin. Fuse and relay module, rear n10/2 3. Srb. 3-pin.
330
Plug Mercedes-Benz
$10.50
Mercedes-Benz Diagnostic socket (lamp unit) e1. 5-pin slk2.8. Delivery unit with fill level sensor a92. 5-pin slk2.8. Fuel pump m3/3. 5-pin slk2.8. Plug connection for fuel pump wiring harness x36/3,code a. 5-pin slk2.8.
330
Coupling Housing, Elec Mercedes-Benz
$17.50
Mercedes-Benz Wiper motor m6/1. 4-pin slk2.8. Left lighting unit e1. 4-pin slk2.8. Diagnostic socket (lamp unit) e1. 4-pin slk2.8. Plug connection for fuel pump wiring harness x36/3. 4-pin slk2.8. Engine cable harness plug-connection x26. 4-pin slk2.8. Lighting unit e1 e2 (s1). 4-pin slk2.8. Connector X26/2 Engine connecting point. 4-PIN SLK2.8. Plug connection engine/body x26/2. 4-pin slk2.8. Headlamp range adjustment left. 4-pin slk2.8. Lamp unit left and right e1/e2. 4-pin slk2.8.
340
Housing Mercedes-Benz
Mercedes-Benz Dynamic seat pump A77. 5-PIN MQS, MCP2.8Model 1: MQS/MCPModel 2: 2.8Slots: 5Release tool: W220 589 01 99 60 / W000 589 13 99 30. Sam/srb control module rear neutral n10/2,. 5-pin mqs, mcp2.8model 1: mqs/mcpmodel 2: 2.8slots: 5release tool: w220 589 01 99 6 ...
340
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Rear sam/srb control module, green n10/2. 5-pin mqs/mcp2.8. Fuse and relay module, rear n10/2 /23. 5-pin mqs/mcp2.8.
350
Coupling, Mechanical Mercedes-Benz
$5.75
Mercedes-Benz Control module sam/srb rear n10/2. 7-pin jpt. Tail lamp. 7-pin jpt.
355
Plug Mercedes-Benz
Mercedes-Benz Stop lamp switch, neutral s9/1. 3-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 3release tool: w000 589 13 99 30. Front sam/srb control module, neutral n10/1,. 3-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 3release tool: w000 589 13 99 30. Sam/srb control module r ...
360
Plug Mercedes-Benz
Mercedes-Benz Contact strip driver side yellow x55/3. 12-pin. Intermediate connector, airbag. 12-pin. Cockpit cable harness plug-connection. 12-pin.
400
Electric Line Mercedes-Benz
$9.00
Mercedes-Benz WITHOUT SEAL. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
405
Contact Socket Mercedes-Benz
$3.70
Mercedes-Benz DOOR LOCK. 0.5-0.75 MM2 SLK2.8Leitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: AgELA: +Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 09. Airbag trigger unit, in front module left and right b48/1. Lighting ...
410
Male Spade Connector Mercedes-Benz
$4.00
Mercedes-Benz Tin-plated. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 1.5-2.5 MM2 SLK2.8Leitun ...
420
Electric Line Mercedes-Benz
$9.50
Mercedes-Benz Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
430
Electric Line Mercedes-Benz
$11.50
Mercedes-Benz WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
440
Contact Spring Mercedes-Benz
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
440
Spring Retaining Pin Mercedes-Benz
$3.90
Mercedes-Benz Contact Spring
1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
460
Electrical Line Mercedes-Benz
$9.75
Mercedes-Benz WITH GASKET. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. With single-wire seal. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
470
Contact Spring Mercedes-Benz
$4.90
Mercedes-Benz Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
480
Contact Socket Mercedes-Benz
$5.75
Mercedes-Benz STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
480
Contact Socket Mercedes-Benz
$7.00
Mercedes-Benz BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
490
Female Spade Connector Mercedes-Benz
$4.70
Mercedes-Benz Silver-plated. 1.5-2.5 MM2 PL6.3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: PL
Model 2: 6.3.
500
Plug Mercedes-Benz
$4.40
Mercedes-Benz Module box separation point x35/15. 3-pin. Radio remote control separation point for central locking x35/71. 3-pin. Separation point trunk lid 14-pin x8/4. 3-pin. Control unit box/engine sep. Point x35/63. 3-pin.
530
Contact Socket Mercedes-Benz
$7.00
Mercedes-Benz DOOR SEPARATION POINT, REAR X35/3,X35/4. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AuELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Copper. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: ...
998
Electric Line Mercedes-Benz
$63.00
Mercedes-Benz Repair Kit
Emergency tensioning retractors front and rear. Front passenger airbag, green. Front left belt tens. R12/1. Rear left belt tensioner r12/6. Squib 2 airbag passenger side r12/5. Passenger airbag, ignition squib 2 r12/5.
999
Repair Kit Mercedes-Benz
Mercedes-Benz Driver seat belt force limiter R12/27. 2-PIN. Front passenger airbag, green r12/5. 2-pin. Front passenger airbag, yellow. 2-pin. Squib 1 airbag passenger side r12/4. 2-pin. Left windowbag r12/22. 2-pin.
999
Electric Line Mercedes-Benz
$59.00
Mercedes-Benz Passenger airbag, ignition squib 1 r12/4. Driver seat belt force limiter R12/27. Front passenger airbag, green r12/5. Front passenger airbag, yellow. Squib 1 airbag passenger side r12/4. Left windowbag r12/22.
