Cable Harness for Comtrol Display System Oms for 2006 Mercedes-Benz C230
No.
Part # / Description / Price
20
Receptacle Housing
Mercedes-Benz
$4.50
Mercedes-Benz Operating unit. 18-pin mqs
model 1: mqs
slots: 18. Automatic air conditioner. 18-pin mqs
model 1: mqs
slots: 18. Central locking mechanism pump. 18-pin mqs
model 1: mqs
slots: 18. Control unit door. 18-pin mqs
model 1: mqs
slots: 18. Control unit pse. 18-pin mqs
model 1: mqs
slots: 18. Radio navigation control unit 18-polig. 18-pin mqs
model 1: mqs
slots: 18.
24
Plug Mercedes-Benz
$4.20
Mercedes-Benz Cockpit/electric steering lock connector x190. 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. Left rear door connector to frame floor system (x35/3). 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. ...
26
Housing Mercedes-Benz
Mercedes-Benz Transceiver connector, blue x39/5. 10-pin mqs. Telephone-portable ctel separation point, blue x39/37*3. 10-pin mqs. Breakdown/information button conn. X39/48. 10-pin mqs. Blue center console connector x29/6. 10-pin mqs. Plug connection handy x39/39. 10-pin mqs. Mobile phone disconnecting point. 10-pin mqs. Connector, telephone, armrest, blue x39/47. 10-pin mqs.
38
Cover Cap Mercedes-Benz
Mercedes-Benz Speed-sensitive power steering conn. Antenna module. 6-pin. Antenna amplifier to rear window to 001 545 51 40. 6-pin.
48
Fuse Mercedes-Benz
$5.00
Mercedes-Benz Fuse Link
Charge level recognition f96. Rear fuse box. Blade fuse ATO. Front, 7.5 amp. Trunk, 7.5 amp. Interior, 7.5 amp. Slot 16 lumbar support adjustment. Slot 3, portable ctel uhi.
50
Receptacle Housing Mercedes-Benz
Mercedes-Benz Comand control panel, black. 8-pin. Ignition lock. 8-pin. Operating unit. 8-pin. Radio navigation control unit 8-polig. 8-pin. Video and control unit. 8-pin.
52
Plug Mercedes-Benz
Mercedes-Benz Electronic ignition lock (ezs) control unit n73*2. 2-pin mcp2.8. Signal acquisition and actuation module with rear fuse and relay module. 2-pin mcp2.8. Front sam/srb control module, neutral n10/1,. 2-pin mcp2.8. Sam/srb control module rear neutral n10/2, code b. 2-pin mcp2.8. Fuse and relay module, driver n10/1 / 11. 2-pin mcp2.8.
54
Housing Mercedes-Benz
$3.20
Mercedes-Benz CONNECTOR: A26/17*1C. 12-PIN MQS
Model 1: MQS
Slots: 12
Release tool: W220 589 01 99 60. Audio/comand control panel a40/3*c. 12-pin mqs
model 1: mqs
slots: 12
release tool: w220 589 01 99 60.
57
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Rear sam/srb control module, green n10/2. 5-pin mqs/mcp2.8. Fuse and relay module, rear n10/2 /23. 5-pin mqs/mcp2.8.
58
Line Connector Mercedes-Benz
$7.00
Mercedes-Benz Connector distributor wake-up/ diagnostics 10-pin x30/14. 10-pin slk2.8. Distributor, terminal 58d x30/13. 10-pin slk2.8. Connector distributor wake-up/ diagnostics 10-pin x 30/14. 10-pin slk2.8. Potential distributor kl.31 z204/5. 10-pin slk2.8. Plug distributor wake-up signal 10 pin x30/8,. 10-pin slk2.8. Below left rear seat z204/6. 10-pin slk2.8. Distributor, terminal 15 x30/9,code a. 10-pin slk2.8.
60
Housing Mercedes-Benz
$4.40
Mercedes-Benz Media interface n125/1. Digital radio control unit n87/3. Comand control panel, black a40/3 1a. 4-pin mqsmodel 1: mqsslots: 4release tool: w220 589 01 99 60. Operating unit a40/3. 4-pin mqsmodel 1: mqsslots: 4release tool: w220 589 01 99 60. Satellite radi ...
62
Plug Mercedes-Benz
$5.00
Mercedes-Benz Plug distributor radio mute x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio "mute" plug connection x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. ...
64
Receptacle Housing Mercedes-Benz
$3.40
Mercedes-Benz Left/right entrance/ex it lamp. 2 pin jpt. Luggage compartment lamp. 2 pin jpt. Glove compartment lamp. 2 pin jpt. Glove box lamp E13/1. 2 PIN JPT. Driver and front passenger footwell lamp e17/15, e17/16. 2 pin jpt. Left exit lights. 2 pin jpt. Courtesy lamp. 2 pin jpt. Interface. 2 pin jpt. Glove compartment lighting e13/2. 2 pin jpt. Vanity mirror illumination e14/6 e14/7. 2 pin jpt.
70
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Sam/srb control module rear violet n10/2,code d. 4-pin mcp2.8. Fuse and relay box, rear n10/2. 4-pin mcp2.8.
73
Crimp Tml Pin Contact Mercedes-Benz
$2.80
Mercedes-Benz Crimp Tml. Pin Contact
X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
74
Electric Line Mercedes-Benz
$9.50
Mercedes-Benz Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
76
Male Spade Connector Mercedes-Benz
$4.20
Mercedes-Benz Silver-plated. 0.22-0.35 MM2 SLK2.8Leitungsquerschnitt Min/Max: 0,22-0,35mm2Oberflächenschutz PINs: AgELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. Single-wire seal. 0.22-0.35 MM2 SLK2.8Leitungsquerschnitt Min ...
77
Contact Socket Mercedes-Benz
$7.00
Mercedes-Benz BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
79
Contact Socket Mercedes-Benz
$5.75
Mercedes-Benz STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
82
Contact Spring Mercedes-Benz
$3.90
Mercedes-Benz Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
88
Contact Spring Mercedes-Benz
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
