Cable Harness for Radio, Loudspeaker and CD-Player for 2006 Mercedes-Benz C230
No.
Part # / Description / Price
11
15
Clutch Housing
Mercedes-Benz
Mercedes-Benz Connector: a1. 8-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 8. Loudspeaker connection a2. 8-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 8. Comand a40/3. 8-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 8. COMAND/Audio. plug: A26/17*A1B. 8-PIN MCP2.8
Model 1: MCP
Model 2: 2.8
Slots: 8.
17
Locking Bolt Mercedes-Benz
$4.50
Mercedes-Benz Audio/comand control panel a40/3*a2. To a 001 545 15 30. Contact fuse TO A0015456930. A0035453640. To a0015451530. Comand/audio. plug: to a0015456930. Contact protection to a0015456930, a0035453040. Audio/comand control panel a40/3*2. Contact protection to a 003 545 30 40.
17
Contact Support Mercedes-Benz
$18.50
Mercedes-Benz Connector: a2. 8-pin mcp2.8. Power supply radio/comand a2. 8-pin mcp2.8. Comand code a, a40/3. 8-pin mcp2.8. Comand control panel, black a40/3*a. 8-pin mcp2.8. Comand/audio. plug: a26/17*a2b. 8-pin mcp2.8.
20
Spring Retaining Pin Mercedes-Benz
$3.90
Mercedes-Benz Contact Spring
1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
24
Plug Mercedes-Benz
$4.20
Mercedes-Benz Cockpit/electric steering lock connector x190. 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. Left rear door connector to frame floor system (x35/3). 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. ...
25
Plug Mercedes-Benz
$7.50
Mercedes-Benz Hitching mechanism plug-connection x52. 4-pin slk 2.8
model 1: slk
model 2: 2.8
slots: 4. Electrical center at trailer control unit x58/33. 4-pin slk 2.8
model 1: slk
model 2: 2.8
slots: 4. Door partition point front left, blue x35/41,. 4-pin slk 2.8
model 1: slk
model 2: 2.8
slots: 4.
26
Housing Mercedes-Benz
Mercedes-Benz Transceiver connector, blue x39/5. 10-pin mqs. Telephone-portable ctel separation point, blue x39/37*3. 10-pin mqs. Breakdown/information button conn. X39/48. 10-pin mqs. Blue center console connector x29/6. 10-pin mqs. Plug connection handy x39/39. 10-pin mqs. Mobile phone disconnecting point. 10-pin mqs. Connector, telephone, armrest, blue x39/47. 10-pin mqs.
33
Plug Mercedes-Benz
$5.00
Mercedes-Benz Plug distributor radio mute x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio "mute" plug connection x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. ...
35
Male Spade Connector Mercedes-Benz
$4.00
Mercedes-Benz Tin-plated. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 1.5-2.5 MM2 SLK2.8Leitun ...
38
Cover Cap Mercedes-Benz
Mercedes-Benz Speed-sensitive power steering conn. Antenna module. 6-pin. Antenna amplifier to rear window to 001 545 51 40. 6-pin.
42
Electric Line Mercedes-Benz
$9.50
Mercedes-Benz Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
48
Fuse Mercedes-Benz
$5.00
Mercedes-Benz Fuse Link
Charge level recognition f96. Rear fuse box. Blade fuse ATO. Front, 7.5 amp. Trunk, 7.5 amp. Interior, 7.5 amp. Slot 16 lumbar support adjustment. Slot 3, portable ctel uhi.
52
Plug Mercedes-Benz
Mercedes-Benz Electronic ignition lock (ezs) control unit n73*2. 2-pin mcp2.8. Signal acquisition and actuation module with rear fuse and relay module. 2-pin mcp2.8. Front sam/srb control module, neutral n10/1,. 2-pin mcp2.8. Sam/srb control module rear neutral n10/2, code b. 2-pin mcp2.8. Fuse and relay module, driver n10/1 / 11. 2-pin mcp2.8.
54
Housing Mercedes-Benz
$3.20
Mercedes-Benz CONNECTOR: A26/17*1C. 12-PIN MQS
Model 1: MQS
Slots: 12
Release tool: W220 589 01 99 60. Audio/comand control panel a40/3*c. 12-pin mqs
model 1: mqs
slots: 12
release tool: w220 589 01 99 60.
58
Line Connector Mercedes-Benz
$7.00
Mercedes-Benz Connector distributor wake-up/ diagnostics 10-pin x30/14. 10-pin slk2.8. Distributor, terminal 58d x30/13. 10-pin slk2.8. Connector distributor wake-up/ diagnostics 10-pin x 30/14. 10-pin slk2.8. Potential distributor kl.31 z204/5. 10-pin slk2.8. Plug distributor wake-up signal 10 pin x30/8,. 10-pin slk2.8. Below left rear seat z204/6. 10-pin slk2.8. Distributor, terminal 15 x30/9,code a. 10-pin slk2.8.
64
Receptacle Housing Mercedes-Benz
$3.40
Mercedes-Benz Left/right entrance/ex it lamp. 2 pin jpt. Luggage compartment lamp. 2 pin jpt. Glove compartment lamp. 2 pin jpt. Glove box lamp E13/1. 2 PIN JPT. Driver and front passenger footwell lamp e17/15, e17/16. 2 pin jpt. Left exit lights. 2 pin jpt. Courtesy lamp. 2 pin jpt. Interface. 2 pin jpt. Glove compartment lighting e13/2. 2 pin jpt. Vanity mirror illumination e14/6 e14/7. 2 pin jpt.
71
Housing Mercedes-Benz
Mercedes-Benz Dynamic seat pump A77. 5-PIN MQS, MCP2.8Model 1: MQS/MCPModel 2: 2.8Slots: 5Release tool: W220 589 01 99 60 / W000 589 13 99 30. Sam/srb control module rear neutral n10/2,. 5-pin mqs, mcp2.8model 1: mqs/mcpmodel 2: 2.8slots: 5release tool: w220 589 01 99 6 ...
71
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Rear sam/srb control module, green n10/2. 5-pin mqs/mcp2.8. Fuse and relay module, rear n10/2 /23. 5-pin mqs/mcp2.8.
73
Crimp Tml Pin Contact Mercedes-Benz
$2.80
Mercedes-Benz Crimp Tml. Pin Contact
X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
75
Electric Line Mercedes-Benz
$11.50
Mercedes-Benz WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
76
Male Spade Connector Mercedes-Benz
$4.20
Mercedes-Benz Silver-plated. 0.22-0.35 MM2 SLK2.8Leitungsquerschnitt Min/Max: 0,22-0,35mm2Oberflächenschutz PINs: AgELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. Single-wire seal. 0.22-0.35 MM2 SLK2.8Leitungsquerschnitt Min ...
77
Contact Socket Mercedes-Benz
$7.00
Mercedes-Benz BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
79
Contact Socket Mercedes-Benz
$5.75
Mercedes-Benz STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
81
Housing Mercedes-Benz
$4.40
Mercedes-Benz Media interface n125/1. Digital radio control unit n87/3. Comand control panel, black a40/3 1a. 4-pin mqsmodel 1: mqsslots: 4release tool: w220 589 01 99 60. Operating unit a40/3. 4-pin mqsmodel 1: mqsslots: 4release tool: w220 589 01 99 60. Satellite radi ...
81
Housing Mercedes-Benz
$6.25
Mercedes-Benz Comand control panel, black. 6-pin mqs, most
model 1: mqs
slots: 6
release tool: w220 589 01 99 60. Audio gateway control module (n93/1). 6-pin mqs, most
model 1: mqs
slots: 6
release tool: w220 589 01 99 60. Satellite radio control unit n87/5. 6-pin mqs, most
model 1: mqs
slots: 6
release tool: w220 589 01 99 60.
82
Contact Spring Mercedes-Benz
$3.90
Mercedes-Benz Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
88
Contact Spring Mercedes-Benz
$3.50
Mercedes-Benz Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
125
130
Plug Mercedes-Benz
Mercedes-Benz Front door speaker h4/5, h4/6. 6-pin. Front door speaker h 4/3. 6-pin. Roller blind motor m 24. 6-pin. Loudspeaker. 6-pin. Right tail lamp. 6-pin. License plate lamp e19/1. E19/2. 6-pin.
130
Plug Mercedes-Benz
Mercedes-Benz Stop lamp switch, neutral cod. B. 3-pin jpt. Loudspeaker. 3-pin jpt. Wiper motor. 3-pin jpt. Subwoofer speaker h4/29. 3-pin jpt.
146
150
170
Plug Mercedes-Benz
$5.50
Mercedes-Benz Left front door connector, green x35/1. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Emergency speaker connector right front x18/36. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pin slk2 ...
220
Receptacle Housing Mercedes-Benz
Mercedes-Benz Operating unit a2. 10-pin jpt. Radio 10-polig. 10-pin jpt. Radio set,10-pole. 10-pin jpt.
310
Electric Line Mercedes-Benz
$8.00
